Pilot Topobathymetric Terrain Model of the Kootenai River near Bonners Ferry, Idaho, 2009 - 2019

April 14, 2021

The U.S. Geological Survey (USGS) 3D Elevation Program (3DEP) has started to initiate the development of pilot 3D National Topography Models to generate 3-dimensional surface elevation models that integrate river topographic bare-earth elevation surfaces with channel bed bathymetry. Detailed knowledge of integrated river system topography, bathymetry, and topobathymetry, is essential for habitat restoration, hydrologic modeling, and other key science applications such as flood mapping and identification of fluvial geomorphic features. An integrated 1-meter topobathymetric digital elevation model (TBDEM) for the Kootenai River near Bonners Ferry, Idaho, has been developed for this first pilot study. The Kootenai River is one of the upper most major tributaries of the Columbia River, flowing from British Columbia through Montana and the Idaho Panhandle then back into Canada, The Kootenai River TBDEM comprises the spatial integration of 10 different geospatial elevation sources including the USGS 3DEP topobathymetric lidar data, existing topographic lidar, and multi-beam acoustic surveys obtained from the U.S. Army Corps of Engineers , and the USGS Idaho Water Science Center. The TBDEM will provide a fundamental baseline for hydrographic and geomorphic applications to support restoration strategies for the white sturgeon habitat and enhanced 2D/3D hydrologic modeling . To develop the Kootenai River TBDEM, the USGS 3DEP acquired topobathymetric (green wavelength) lidar in 2017 for the Kootenai River near Bonners Ferry, Idaho that successfully captured primary deposition areas, secondary channels, and bank to bank (submerged topography) coverage of straight, meander, and shallow braided sections of the river. Topobathymetric lidar data were spatially integrated with topographic lidar and sonar data to create a seamless TBDEM void of gaps and with complete coverage for the Kootenai River pilot study area. The integration process includes a critical step where the topography, topobathymetry, and bathymetry data are sorted and prioritized based on survey date, accuracy, spatial distribution, and point density to develop a TBDEM based on the best available elevation data. Every input data source in the TBDEM has been horizontally referenced to UTM Zone 11, NAD83 2011 and vertically referenced to the North American Vertical Datum of 1988 (NAVD88) Geoid12b. The spatial resolution is 1-meter with general thalweg elevations ranging from 541 meters in the upstream segment to 521 meters in the downstream segment. The overall temporal range of the input topography, topobathymetry, and bathymetry is 2009 to 2019.

Publication Year 2021
Title Pilot Topobathymetric Terrain Model of the Kootenai River near Bonners Ferry, Idaho, 2009 - 2019
DOI 10.5066/P9Q3VAY8
Authors Jeffrey J Danielson, Cynthia Miller-Corbett, Cindy Thatcher
Product Type Data Release
Record Source USGS Asset Identifier Service (AIS)
USGS Organization Earth Resources Observation and Science (EROS) Center
Rights This work is marked with CC0 1.0 Universal
