Velocity Survey at Cross Sections in the Illinois River below Starved Rock Lock and Dam near Utica, Illinois, June 16, 2021

In support of U.S. Geological Survey invasive carp research examining aggregations of invasive carp in the tail water of dams, water velocity measurements were made at cross sections in the Illinois River below Starved Rock Lock and Dam on June 16, 2021. A total of 16 cross sections were surveyed, with two transects per cross section. Water depth and crew safety limited the extent of the survey. The discharge in the Illinois River at Starved Rock Lock and Dam at the time of data collection was approximately 185.7 cubic meters per second. The data were processed in the Velocity Mapping Toolbox (VMT) v.4.09 (Parsons and others, 2013) to obtain a depth-averaged velocity field for each cross section from paired transects at each cross section.

References Cited:

Parsons, D.R., Jackson, P.R., Czuba, J.A., Engel, F.L., Rhoads, B.L., Oberg, K.A., Best, J.L., Mueller, D.S., Johnson, K.K. and Riley, J.D., 2013, Velocity Mapping Toolbox (VMT): a processing and visualization suite for moving-vessel ADCP measurements, Earth Surface Processes and Landforms, v. 38, no. 11, p. 1244–1260. [Also available at https://doi.org/10.1002/esp.3367].
