Estimated hydrogeologic, spatial, and temporal distribution of self-supplied domestic groundwater withdrawals for aquifers of the Virginia Coastal Plain

Water use from private-domestic wells accounts for nearly 40 percent of total groundwater withdrawals in the Virginia Coastal Plain Physiographic Province (henceforth called the Virginia Coastal Plain). However, because self-supplied domestic water use generally falls below the Virginia Department of Environmental Quality (VDEQ) reporting and management threshold of 300,000 gallons per month, quantifying these withdrawals is challenging. This report builds upon the foundation of previous U.S. Geological Survey investigations by providing revised techniques to improve estimates of the aquifer source, spatial distribution, and monthly magnitude of these groundwater withdrawals.

The aquifer sources of private-domestic wells in the Virginia Coastal Plain were estimated by cross-referencing 8,264 well records from the VDEQ and the Virginia Department of Health to a digital model of the Virginia Coastal Plain hydrogeologic framework. This analysis highlights the regional importance of the Yorktown-Eastover, Potomac, and surficial aquifers. Collectively, these three aquifers account for 80 percent of self-supplied domestic groundwater withdrawals.

The population using self-supplied domestic water was estimated using census blocks, well-use ratios, building footprints, and land-use and land-cover data to produce a high-resolution, disaggregated, raster-based dataset. This approach improves upon previous models at the census-block or road-network scale by reducing the low-density spread of the self-supplied domestic population across undeveloped areas and concentrating the population and its corresponding water use in the areas where it is most likely to occur. Results show that an estimated 475,332 people comprise the 2020 self-supplied domestic population of the Virginia Coastal Plain, an increase of 5.7 percent since 2010, and the greatest concentrations of self-supplied domestic population surround large cities. Estimates could be further refined with the addition of current and complete spatial data on public water-system service areas.

The quantity of water used by the self-supplied domestic population was estimated by modifying published state per-capita water-use coefficients with the corresponding monthly variability assessed from Virginia Coastal Plain public water-system withdrawal data. This analysis estimates an average increase of 12 percent from June through August and an average decrease of 8 percent from December through March from the baseline annual average of 80 gallons per day per capita, which generally matches similar studies in the eastern United States.

The application of these revised methodologies for the estimation of private-domestic wells and the self-supplied domestic population improves understanding of domestic groundwater use in the Virginia Coastal Plain across hydrogeologic, spatial, and temporal scales. These revisions help better inform water-resource managers and decision makers and support higher resolution groundwater modeling. Furthermore, these methods are transferrable to other areas where self-supplied domestic water withdrawals are important to the overall water budget.
