Bathymetric contour maps, surface area and capacity tables, and bathymetric change maps for selected water-supply lakes in northeastern Missouri, 2021

October 6, 2023

Bathymetric data were collected at 12 water-supply lakes in northeastern Missouri by the U.S. Geological Survey (USGS) in cooperation with the Missouri Department of Natural Resources (MoDNR) and various local agencies, as part of a multiyear effort to establish or update the surface area and capacity tables for the surveyed lakes. The lakes were surveyed in March through May 2021. Ten of the lakes had been surveyed previously by the USGS, and the recent surveys were compared to the earlier surveys to document the changes in the bathymetric surface and capacity of the lakes.

Bathymetric data were collected using a high-resolution multibeam mapping system mounted on a boat. Supplemental depth data at five of the lakes were collected in shallow areas with an acoustic Doppler current profiler on a remote-controlled boat. Data points from the various sources were exported at a gridded data resolution appropriate to each lake, either 0.82 foot, 1.64 feet, or 3.28 feet. Data outside the multibeam survey extent and greater than the surveyed water-surface elevation were obtained from data collected using aerial light detection and ranging (lidar) point cloud data. A linear enforcement technique was used to add points to the dataset in areas of sparse data (the upper ends of coves where the water was shallow or aquatic vegetation precluded data acquisition) based on surrounding multibeam and upland data values. The various point datasets were used to produce a three-dimensional triangulated irregular network surface of the lake-bottom elevations for each lake. A surface area and capacity table was produced from the three-dimensional surface for each lake showing surface area and capacity at specified lake water-surface elevations. Various quality-assurance tests were conducted to ensure quality data were collected with the multibeam, including beam angle checks and patch tests. Additional quality-assurance tests were conducted on the gridded bathymetric data from the survey, the bathymetric surface created from the gridded data, and the contours created from the bathymetric survey.

If there were data from a previous bathymetric survey for a given lake, a bathymetric change map was generated from the elevation difference between the previous survey and the 2021 bathymetric survey data points. After reconciling any vertical datum disagreement between the previous survey data and the 2021 survey datum, coincident points between the surveys were identified, and a bathymetric change map was generated using the coincident point data.

The mean elevation change between all repeat surveys at most lakes was positive, indicating sedimentation. Relative to previous surveys, the change in capacity at the primary spillway elevation ranged from a 7.7-percent decrease at Memphis Reservoir to a 3.9-percent increase at Old Lake (Bowling Green West). The mean bathymetric change ranged from 0.03 foot at Hazel Creek and 0.07 foot at Shelbina Lake and Bowling Green Reservoir (Jack Floyd Memorial Lake) to 0.63 at Memphis Lake (Lake Showme) and 0.88 at Memphis Reservoir. The time-averaged mean bathymetric change ranged from 0.002 foot per year at Hazel Creek Lake to 0.044 foot per year at Memphis Reservoir. The computed volumetric sedimentation rate generally ranged from 0.14 to 6.80 acre-feet per year at Shelbina Lake and Memphis Lake (Lake Showme), respectively; however, Forest Lake had a substantially larger sedimentation rate of 17.0 acre-feet per year. Some changes observed in some bathymetric change maps are believed to result from the difference in data collection equipment and techniques between the previous and present bathymetric surveys, whereas other erosional features around the perimeter of certain lakes may be the result of wave action during low-water years.

Publication Year 2023
Title Bathymetric contour maps, surface area and capacity tables, and bathymetric change maps for selected water-supply lakes in northeastern Missouri, 2021
DOI 10.3133/sir20235108
Authors Benjamin C. Rivers, Richard J. Huizinga, Joseph M. Richards, Garett J. Waite
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2023-5108
Index ID sir20235108
Record Source USGS Publications Warehouse
USGS Organization Central Midwest Water Science Center
