Borehole geophysical monitoring of amendment emplacement and geochemical changes during vegetable oil biostimulation, Anoka County Riverfront Park, Fridley, Minnesota

January 1, 2007

The U.S. Geological Survey (USGS) conducted a series of geophysical investigations to monitor a field-scale biostimulation pilot project at the Anoka County Riverfront Park (ACP), downgradient from the Naval Industrial Reserve Ordnance Plant, in Fridley, Minnesota. The pilot project was undertaken by the U.S. Naval Facilities Engineering Command, Southern Division, for the purpose of evaluating biostimulation using emulsified vegetable oil to treat ground water contaminated with chlorinated hydrocarbons. Vegetable oil was introduced to the subsurface to serve as substrate for naturally occurring microbes, which ultimately break down chlorinated hydrocarbons into chloride, carbon dioxide, and water through oxidation-reduction reactions. In support of this effort, the USGS collected cross-borehole radar data and conventional borehole geophysical data in five site visits over 1.5 years to evaluate the effectiveness of geophysical methods for monitoring emplacement of the vegetable oil emulsion and for tracking changes in water chemistry. Radar zero-offset profile (ZOP) data, radar traveltime tomograms, electromagnetic (EM) induction logs, natural gamma logs, neutron porosity logs, and magnetic susceptibility logs were collected and analyzed.

In order to facilitate data interpretation and to test the effectiveness of radar for monitoring oil-emulsion placement and movement, three injection mixtures with different radar signatures were used: (1) vegetable oil emulsion, (2) vegetable oil emulsion with a colloidal iron tracer, and (3) vegetable oil emulsion with a magnetite tracer. Based on petrophysical modeling, mixture (1) was expected to increase radar velocity and decrease radar attenuation relative to background—a water-saturated porous medium; mixtures (2) and (3) were expected to increase radar velocity and increase radar attenuation because of their greater electrical conductivity compared to background ground water.

Radar ZOP data and tomograms show increased EM velocity in the vicinity of injection wells. Comparison of pre- and post-injection datasets shows that velocity anomalies are observed only in planes connected to injection wells, indicating that the emulsified vegetable oil does not migrate far after injection. In contrast to the localization of velocity anomalies, radar attenuation anomalies are observed in all zero-offset profiles, particularly those downgradient from the injection wells. Despite the expected signatures of different tracers, increases in attenuation are observed downgradient from all three injection wells; thus, we infer that the attenuation changes do not result from the iron tracers alone. Over the period of data collection, the slowness (reciprocal velocity) anomalies are relatively stable, whereas the attenuation anomalies generally increase in magnitude and extent. One explanation for the attenuation changes is that products of vegetable oil-enhanced biodegradation (for example, chloride) increase the specific conductance of ground water and thus bulk electrical conductivity and radar attenuation. This interpretation is supported by the results of EM-induction and magnetic susceptibility logs, which indicate increases in electrical conductivity in the absence of magnetic anomalies that might result from the iron and magnetite.

Based on the geophysical data, conceptual models of the distributions of emulsified vegetable oil and ground water with altered chemistry were developed. The field data indicate that, in several cases, the plume of ground water with altered chemistry would not be detected by direct chemical sampling given the construction of monitoring wells; hence the geophysical data provide valuable site-specific insights for the interpretation of water samples and monitoring of biostimulation projects. Application of geophysical methods to data from the ACP demonstrated the utility of radar for monitoring biostimulation injections.

Publication Year 2007
Title Borehole geophysical monitoring of amendment emplacement and geochemical changes during vegetable oil biostimulation, Anoka County Riverfront Park, Fridley, Minnesota
DOI 10.3133/sir20065199
Authors John W. Lane, Frederick D. Day-Lewis, Carole D. Johnson, Peter K. Joesten, Christopher S. Kochiss
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2006-5199
Index ID sir20065199
Record Source USGS Publications Warehouse
USGS Organization Minnesota Water Science Center; Office of Ground Water
