California State Waters Map Series—Offshore of Gaviota, California

April 20, 2018

Introduction

In 2007, the California Ocean Protection Council initiated the California Seafloor Mapping Program (CSMP), designed to create a comprehensive seafloor map of high-resolution bathymetry, marine benthic habitats, and geology within the 3-nautical-mile limit of California’s State Waters. The CSMP approach is to create highly detailed seafloor maps through collection, integration, interpretation, and visualization of swath sonar data, acoustic backscatter, seafloor video, seafloor photography, high-resolution seismic-reflection profiles, and bottom-sediment sampling data. The map products display seafloor morphology and character, identify potential marine benthic habitats, and illustrate both the surficial seafloor geology and shallow subsurface geology.

The map area is in the southern part of the Western Transverse Ranges geologic province, which is north of the California Continental Borderland. Significant clockwise rotation—at least 90°—since the early Miocene has been proposed for the Western Transverse Ranges province, and the region is presently undergoing north-south shortening. The offshore part of the map area lies south of the steep south flank of the Santa Ynez Mountains. The crest of the range, which has a maximum elevation of about 760 m in the map area, lies about 4 km north of the shoreline.

Gaviota is an unincorporated community that has a sparse population (less than 100), and the coastal zone is largely open space that is locally used for cattle grazing. The Union Pacific railroad tracks extend westward along the coast through the entire map area, within a few hundred meters of the shoreline. Highway 101 crosses the eastern part of the map area, also along the coast, then turns north (inland) and travels through Cañada de la Gaviota and Gaviota Pass en route to Buellton. Gaviota State Park lies at the mouth of Cañada de la Gaviota. West of Gaviota, the onland coastal zone is occupied by the Hollister Ranch, a privately owned, gated community that has no public access.

The map area has a long history of petroleum exploration and development. Several offshore gas fields were discovered and were developed by onshore directional drilling in the 1950s and 1960s. Three offshore petroleum platforms were installed in adjacent federal waters in 1976 (platform “Honda”) and 1989 (platforms “Heritage” and “Harmony”). Local offshore and onshore operations were serviced for more than a century by the Gaviota marine terminal, which is currently being decommissioned and will be abandoned in an intended transition to public open space.

 The Offshore of Gaviota map area lies within the western Santa Barbara Channel region of the Southern California Bight, and it is somewhat protected from large Pacific swells from the north and northwest by Point Conception and from south and southwest swells by offshore islands and banks. Much of the shoreline in the map area is characterized by narrow beaches that have thin sediment cover, backed by low (10- to 20-m-high) cliffs that are capped by a narrow coastal terrace. Beaches are subject to wave erosion during winter storms, followed by gradual sediment recovery or accretion in the late spring, summer, and fall months during the gentler wave climate.

The map area lies in the western-central part of the Santa Barbara littoral cell, which is characterized by west-to-east transport of sediment from Point Arguello on the northwest to Hueneme and Mugu Canyons on the southeast. Sediment supply to the western and central part of the littoral cell is mainly from relatively small coastal watersheds. In the map area, sediment sources include Cañada de la Gaviota (52 km2), as well as Cañada de la Llegua, Arroyo el Bulito, Cañada de Santa Anita, Cañada de Alegria, Cañada del Agua Caliente, Cañada del Barro, Cañada del Leon, Cañada San Onofre, and many others. Coastal-watershed discharge and sediment load are highly variable, characterized by brief large events during major winter storms and long periods of low (or no) flow and minimal sediment load between storms. In recent (recorded) history, the majority of high-discharge, high-sediment-flux events have been associated with El Niño phases of the El Niño–Southern Oscillation climatic pattern.

Shelf width in the Offshore of Gaviota map area ranges from about 4.3 to 4.7 km, and shelf slopes average about 1.0° to 1.2° but are highly variable because of the presence of the large Gaviota sediment bar. This bar extends southwestward for about 9 km from the mouth of Cañada de la Gaviota to the shelf break, is as wide as 2 km, and is by far the largest shore-attached sediment bar in the Santa Barbara Channel. The shelf is underlain by bedrock and variable amounts (0 to as much as 36 m in the Gaviota bar) of upper Quaternary sediments deposited as sea level fluctuated in the late Pleistocene. The trend of the shelf break changes from about 276° to 236° azimuth over a distance of about 12 km, and it ranges in depth from about 91 m to as shallow as 62 to 73 m where significant shelf-break and upper-slope failure and landsliding has apparently occurred. The shelf break in the western part of the map area is notably embayed by the heads of three large (150- to 300-m-wide) channels that have been referred to as “the Gaviota Canyons” or as “Drake Canyon,” “Sacate Canyon,” and “Alegria Canyon.”

Seafloor habitats in the broad Santa Barbara Channel region consist of significant amounts of soft, unconsolidated sediment interspersed with isolated areas of rocky habitat that support kelp-forest communities in the nearshore and rocky-reef communities in deeper water. The potential marine benthic habitat types mapped in the Offshore of Gaviota map area are directly related to its Quaternary geologic history, geomorphology, and active sedimentary processes. These potential habitats lie primarily within the Shelf (continental shelf) but also partly within the Flank (basin flank or continental slope) megahabitats. The fairly homogeneous seafloor of sediment and low-relief bedrock provides characteristic habitat for rockfish, groundfish, crabs, shrimp, and other marine benthic organisms. Several areas of smooth sediment form nearshore terraces that have relatively steep, smooth fronts, which may be attractive to groundfish. Below the steep shelf break, soft, unconsolidated sediment is interrupted by the heads of several submarine canyons and rills, some bedrock exposures, and small carbonate mounds associated with asphalt mounds and pockmarks, also good potential habitat for rockfish. The map area includes the relatively small (5.2 km2) Kashtayit State Marine Conservation Area, which largely occupies the inner part of the Gaviota sediment bar.
