Empirical, dimensionless, cumulative-rainfall hyetographs developed from 1959-86 storm data for selected small watersheds in Texas

A database of incremental cumulative-rainfall values for storms that occurred in small urban and rural watersheds in north and south central Texas during the period from 1959 to 1986 was used to develop empirical, dimensionless, cumulative-rainfall hyetographs. Storm-quartile classifications were determined from the cumulative-rainfall values, which were divided into data groups on the basis of storm-quartile classification (first, second, third, fourth, and first through fourth combined), storm duration (0 to 6, 6 to 12, 12 to 24, 24 to 72, and 0 to 72 hours), and rainfall amount (1 inch or more). Removal of long leading tails, in effect, shortened the storm duration and, in some cases, affected the storm-quartile classification. Therefore, two storm groups, untrimmed and trimmed, were used for analysis. The trimmed storms generally are preferred for interpretation. For a 12-hour or less trimmed storm duration, approximately 49 percent of the storms are first quartile. For trimmed storm durations of 12 to 24 and 24 to 72 hours, 47 and 38 percent, respectively, of the storms are first quartile. For a trimmed storm duration of 0 to 72 hours, the first-, second-, third-, and fourth-quartile storms accounted for 46, 21, 20, and 13 percent of all storms, respectively.

The 90th-percentile curve for first-quartile storms indicated about 90 percent of the cumulative rainfall occurs during the first 20 percent of the storm duration. The 10th-percentile curve for first-quartile storms indicated about 30 percent of the cumulative rainfall occurs during the first 20 percent of the storm duration. The 90th-percentile curve for fourth-quartile storms indicated about 33 percent of the cumulative rainfall occurs during the first 20 percent of the storm duration. The 10th-percentile curve for fourth-quartile storms indicated less than 5 percent of the cumulative rainfall occurs during the first 20 percent of the storm duration.

Statistics for the empirical, dimensionless, cumulative-rainfall hyetographs are presented in the report along with hyetograph curves and tables. The curves and tables presented do not present exact mathematical relations but can be used to estimate distributions of rainfall with time for small drainage areas of less than about 160 square miles in urban and small rural watersheds in north and south central Texas.
