Hydraulic and biological analysis of the passability of select fish species at the U.S. Geological Survey streamgaging weir at Blackwells Mills, New Jersey

Recent efforts to advance river connectivity for the Millstone River watershed in New Jersey have led to the evaluation of a low-flow gauging weir that spans the full width of the river. The methods and results of a desktop modelling exercise were used to evaluate the potential ability of three anadromous fish species (Alosa sapidissima [American shad], Alosa pseudoharengus [alewife], and Alosa aestivalis [blueback herring]) to pass upstream over the U.S. Geological Survey Blackwells Mills streamgage (01402000) and weir on the Millstone River, New Jersey, at various streamflows, and to estimate the probability that the weir will be passable during the spring migratory season.

 Based on data from daily fishway counts downstream from the Blackwells Mills streamgage and weir between 1996 and 2014, the general migratory period was defined as April 14 to May 28. Recorded water levels and flow data were used to theoretically estimate water depths and velocities over the weir, as well as flow exceedances occurring during the migratory period.

Results indicate that the weir is a potential depth barrier to fish passage when streamflows are below 200 cubic feet per second using a 1-body-depth criterion for American shad (the largest fish among the target species). Streamflows in that range occur on average 35 percent of the time during the migratory period. An increase of the depth criterion to 2 body depths causes the weir to become a possible barrier to passage when flows are below 400 cubic feet per second. Streamflows in that range occur on average 73 percent of the time during the migration season. Average cross-sectional velocities at several points along the weir do not seem to be limiting to the fish migration, but maximum theoretical velocities estimated without friction loss over the face of the weir could be potentially limiting.
