Hydrographic survey of Chaktomuk, the confluence of the Mekong, Tonlé Sap, and Bassac Rivers near Phnom Penh, Cambodia, 2012

January 1, 2014

The U.S. Geological Survey, in cooperation with the U.S. Department of State, Mekong River Commission, Phnom Penh Autonomous Port, and the Cambodian Ministry of Water Resources and Meteorology, completed a hydrographic survey of Chaktomuk, which is the confluence of the Mekong, Tonlé Sap (also spelled Tônlé Sab), and Bassac Rivers near Phnom Penh, Cambodia. The hydrographic survey used a high-resolution multibeam echosounder mapping system to map the riverbed during April 21–May 2, 2012.

The multibeam echosounder mapping system was made up of several components: A RESON Seabat™ 7125 multibeam echosounder, an inertial measurement unit and navigation unit, data collection computers, and a Real-Time Kinematic (RTK) Global Navigation Satellite System (GNSS) base station. The survey area was divided into six survey subreaches and each subreach was surveyed within 3 days along survey lines oriented parallel to the flow direction. Complete coverage of the riverbed was the operational objective; however, to obtain broad spatial coverage, gaps between parallel swaths were permitted, especially in wide, shallow areas where multibeam swath widths were narrow.

The survey was referenced to two existing bench marks with known geographic coordinates by establishing a GNSS base station on the bench marks each day and using real-time corrections from the base station to correct boat navigation data. The World Geodetic System of 1984 (WGS 84) ellipsoid was used during data collection to reference height, and data were adjusted to the local datum, Ha Tien 1960, during postprocessing.

The quality of hydrographic surveys was described by an uncertainty estimate called total propagated uncertainty (TPU). Calculations of TPU were completed for the hydrographic survey data resulting in the maximum TPU of 0.33 meters. The mean and median TPUs were 0.18 meters, and 99.9 percent of TPU values were less than 0.25 meters.

Detailed hydrographic maps of Mekong, Tonlé Sap, and Bassac Rivers showing the riverbed elevations surveyed April 21–May 2, 2012, referenced to Ha Tien 1960 were produced. The surveyed area included a 2-km stretch of the Mekong River between the confluence with the Tonlé Sap and Bassac Rivers, and extended 4 km upstream and 3.6 km downstream from the 2,000-m confluence stretch of the Mekong River. In addition, 0.7 km of the Bassac River downstream and 3.5 km of the Tonlé Sap River (from the confluence to Chroy Changvar Bridge) upstream from their confluence with the Mekong River were surveyed. Riverbed features (such as dunes, shoals, and the effects of sediment mining, which were observed during data collection) are visible on the hydrographic maps. All surveys were completed at low annual water levels as referenced to nearby Mekong River Commission streamflow-gaging stations. Riverbed elevations surveyed ranged from 24.08 m below to 1.54 m above Ha Tien 1960.

Publication Year 2014
Title Hydrographic survey of Chaktomuk, the confluence of the Mekong, Tonlé Sap, and Bassac Rivers near Phnom Penh, Cambodia, 2012
DOI 10.3133/sir20145227
Authors Benjamin J. Dietsch, Brenda K. Densmore, Richard C. Wilson
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2014-5227
Index ID sir20145227
Record Source USGS Publications Warehouse
USGS Organization Nebraska Water Science Center
