K1-95-HW: Cruise report 1995 - Preliminary results, phase III: Sediment chemistry and biological sampling survey

July 1, 1996

Mamala Bay, off the south shore of the island of Oahu, has been used as a repository of dredged material primarily from Pearl and Honolulu Harbors for over a century. The U.S. Geological Survey, U.S. Army Corps of Engineers, and the U.S. Environmental Protection Agency are conducting an integrated study on the distribution and character of dredged materials as well as the effects of dredged material on the marine environment. A three phase study is providing information to evaluate the effects on seafloor substrate and the benthic fauna. The studies include geophysical profiling and imaging, bottom photography, sampling, chemical and physical analyses of sediment, and evaluations of the benthic population, population density, and adverse impacts to the benthic fauna.

Phase 1, conducted in 1993, inventoried the seafloor via remote sensing. Sidescan sonar and subbottom profilers characterized the seafloor in and around the disposal sites, and the resulting products reveal the character and extent of the dredged material. These data were used to plan Phase 2 in 1994, a sampling program that employed subbottom profilers, video and still photography, and seafloor sampling to ground truth the sonar mosaic and identify the seafloor substrates responsible for the various acoustic signatures on the sonar images and subbottom profiles. Box coring provided the samples necessary to distinguish dredged material from native sediment, and for the chemical analyses used to determine contaminant concentrations. Phase 3 studies conducted in June of 1995 consisted of box core sampling for chemical and biological analyses. Specific studies include: infaunal taxonomy and population density, bioassay/bioaccumulation, sediment chemistry, and post-disposal resuspension and transport.

The 1995 survey, conducted June 14 through 17, resulted in the collection of 39 box cores from 20 different stations. Multiple box cores were composited at 7 different locations occupied in 1994, to provide the material required for the 7 bioassay and bioaccumulation analyses currently underway (Figure 1). Seventeen of the 20 stations occupied provided the biological samples for the benthic infaunal identification and population density study conducted by Dr. Julie Brock of the University of Hawaii, and the sediment chemistry analyses conducted (and completed) by Quanterra Environmental Laboratories (Figure 1). Seven of the 20 stations occupied in 1995 were occupied in 1994, and provide the data for direct comparison of sediment chemistry at the same sites from two consecutive years. The sum total of the data collected from all three phases of the monitoring program will provide the U.S. Army Corps of Engineers and the U.S. Environmental Protection Agency with the information required to make informed decisions as to the management of the South Oahu disposal site in Mamala Bay.

Citation Information

Publication Year 1995
Title K1-95-HW: Cruise report 1995 - Preliminary results, phase III: Sediment chemistry and biological sampling survey
DOI 10.3133/ofr95839
Authors M. E. Torresan, M. A. Hampton, J. H. Barber, F. L. Wong
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Open-File Report
Series Number 95-839
Index ID ofr95839
Record Source USGS Publications Warehouse
USGS Organization Pacific Coastal and Marine Science Center
