Porphyry copper potential of the U.S. Southern Basin and Range using ASTER data integrated with geochemical and geologic datasets to assess potential near-surface deposits in well-explored permissive tracts

September 1, 2019

ArcGIS was used to spatially assess and rank potential porphyry copper deposits using Advanced Spaceborne Thermal Emission and Reflection Radiometer (ASTER) data together with geochemical and geologic datasets in order to estimate undiscovered deposits in the southern Basin and Range Province in the southwestern United States. The assessment was done using a traditional expert opinion three-part method and a prospectivity model developed using weights of evidence and logistic regression techniques to determine if ASTER data integrated with other geologic datasets can be used to find additional areas of prospectivity in well-explored permissive tracts. ASTER hydrothermal alteration data were expressed as 457 alteration polygons defined from a low-pass filtered alteration density map of combined argillic, phyllic, and propylitic rock units. Sediment stream samples were plotted as map grid data and used as spatial information in ASTER polygons. Gravity and magnetic data were also used to define basins greater than 1 km in depth. Each ASTER alteration polygon was ranked for porphyry copper potential using alteration types, spatial amounts of alteration, stream sediment geochemistry, lithology, polygon shape, proximity to other alteration polygons, and deposit and prospects data. Permissive tracts defined for the assessment in the southern Basin and Range Province include the Laramide Northwest, Laramide Southeast, Jurassic, and Tertiary tracts. Expert opinion estimates using the three-part assessment method resulted in a mean estimate of 17 undiscovered porphyry copper deposits, whereas the prospectivity modeling predicted a mean estimate of nine undiscovered deposits. In the well-explored Laramide Southeast tract, which contains the most deposits and has been explored for over 100 years, an average of 4.3 undiscovered deposits was estimated using ASTER alteration polygon data versus 2.8 undiscovered deposits without ASTER data. The Tertiary tract, which contains the largest number of ASTER alteration polygons not associated with known Tertiary deposits, was predicted to contain the most undiscovered resources in the southern Basin and Range Province.
