Preliminary integrated geologic map databases for the United States: Delaware, Maryland, New York, Pennsylvania, and Virginia

October 2, 2005

The growth in the use of Geographic Information Systems (GIS) has highlighted the need for regional and national digital geologic maps attributed with age and lithology information. Such maps can be conveniently used to generate derivative maps for purposes including mineral-resource assessment, metallogenic studies, tectonic studies, and environmental research. This Open-File Report is a preliminary version of part of a series of integrated state geologic map databases that cover the entire United States.

The only national-scale digital geologic maps that portray most or all of the United States for the conterminous U.S. are the digital version of the King and Beikman (1974a, b) map at a scale of 1:2,500,000, as digitized by Schruben and others (1994) and the generalized digital version (Reed and Bush, 2004) of the Geologic Map of North America (Reed and others, 2005a, b) compiled at a scale of 1:5,000,000. The present series of maps is intended to provide the next step in increased detail. State geologic maps that range in scale from 1:100,000 to 1:1,000,000 are available for most of the country, and digital versions of these state maps are the basis for this product. In a few cases, new digital compilations were prepared (e.g. Ohio, South Carloina, South Dakota) or existing paper maps were digitized (e.g. Kentucky, Texas). Also as part of this series, new regional maps for Alaska and Hawaii are being compiled and ultimately new state maps will be produced.

The digital geologic maps are presented in standardized formats as ARC/INFO export (.e00) files and as ArcView shape (.shp) files. Accompanying these spatial databases are a set of five supplemental attribute tables that relate the map units to detailed lithologic and age information. The maps for the CONUS have been fitted to a common set of state boundaries based on the 1:100,000 topographic map series of the United States Geological Survey (USGS). When the individual state maps are merged, the combined attribute tables can be used directly with the merged maps to make derivative maps. No attempt has been made to reconcile differences in mapped geology across state lines.

Publication Year 2005
Title Preliminary integrated geologic map databases for the United States: Delaware, Maryland, New York, Pennsylvania, and Virginia
DOI 10.3133/ofr20051325
Authors Connie L. Dicken, Suzanne W. Nicholson, John D. Horton, Scott A. Kinney, Gregory L. Gunther, Michael P. Foose, Julia A. L. Mueller
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Open-File Report
Series Number 2005-1325
Index ID ofr20051325
Record Source USGS Publications Warehouse
USGS Organization Eastern Mineral and Environmental Resources Science Center
