Seepage investigation of the Rio Grande from below Leasburg Dam, Leasburg, New Mexico, to above American Dam, El Paso, Texas, 2014

Seepage investigations have been conducted annually by the U.S. Geological Survey from 1988 to 1998 and from 2004 to the present (2014) along a 64-mile reach of the Rio Grande from below Leasburg Dam, Leasburg, New Mexico, to above American Dam, El Paso, Texas, as part of the Mesilla Basin monitoring program. Results of the investigation conducted in 2014 are presented in this report. The 2014 seepage investigation was conducted on February 11, 2014, during the low-flow conditions of the non-irrigation season. During the 2014 investigation, discharge was measured at 23 sites along the main-stem Rio Grande and 19 inflow sites within the study reach. Because of extended drought conditions affecting the basin, many sites along the Rio Grande (17 main-stem and 9 inflow) were observed to be dry in February 2014. Water-quality samples were collected during the seepage investigation at sites with flowing water as part of a long-term monitoring effort in the region.

Net seepage gain or loss was computed for each subreach (the interval between two adjacent measurement locations along the river) by subtracting the discharge measured at the upstream location from the discharge measured at the closest downstream location along the river and then subtracting any inflow to the river within the subreach. An estimated gain or loss was determined to be meaningful when it exceeded the cumulative measurement uncertainty associated with the net seepage computation. The cumulative seepage loss in the 64-mile study reach in 2014 was 16.0 plus or minus 2.9 cubic feet per second.
