USGS EROS Archive - Aerial Photography - National Aerial Photography Program (NAPP)
More than 1.3 million cloud-free black-and-white and color infrared aerial photographs over the United States were obtained from an altitude of 20,000 feet.
The National Aerial Photography Program (NAPP) was coordinated by the USGS as an interagency project to acquire cloud-free aerial photographs at an altitude of 20,000 feet above mean terrain elevation. The photographs were taken with a 6-inch focal length lens at a scale of 1:40,000. Coverage over the conterminous United States includes both black-and-white (BW) and color infrared (CIR) aerial photographs. Film type and extent of coverage were determined by available funds and operational requirements.
The NAPP program, which was operational from 1987 to 2007, consists of more than 1.3 million images. Photographs were acquired on 9-inch film and were centered over quarters of USGS 7.5-minute quadrangles.
Film Type
The NAPP collection includes black-and-white and color infrared images.
Black-and-white (BW) panchromatic film is sensitive to the full visible portion of the electromagnetic spectrum of light and captures images in tones of gray ranging from black to white.
Color infrared (CIR), or false color, film is sensitive to green and red in the visible portion of spectrum of light and extends into the near-infrared region of the spectrum. Vegetation is distinctly red to magenta in CIR images because vegetation is highly reflective in the near-infrared portion of the spectrum. CIR photography uses high-speed film that is subject to degradation prior to processing, which can create an overall blue cast to the image.
Scale
The scale of the image is the ratio of the distance on the image compared to the equivalent distance on the ground. An image with a scale of 1:40,000 means that one inch on the photo is equivalent to 40,000 inches on the ground. A 9 x 9-inch image with a scale of 1:40,000 (1 inch equals about 0.6 miles) covers an area of approximately 5.5 x 5.5 miles on the ground.
Recording Technique
Aerial photographs are acquired by aircraft equipped with mapping cameras. The recording technique for the NAPP film collection is vertical photography, which is obtained with the camera pointed directly at the ground.
Flight lines for the NAPP program were flown in a north-to-south direction through the east and west halves of 7.5-minute quadrangles, also known as 1:24,000-scale topographic maps. Images are cartographic quality with a 60% overlap of images to allow for stereographic viewing with specialized equipment.
Quality
Commercial flight contractors were required to meet a stringent list of acceptance criteria in order to fulfill contract requirements. All photographs were manually assessed to ensure that they met the photographic, cartographic, coverage accuracy, and quality standards of the NAPP program.
Even though the images in the NAPP collection met contract requirements, users should note that the images have not been geocorrected. The images may have feature displacement and scale variation caused by differences in elevation, lens distortion, and camera tilt. Since the medium and high resolution digital products are reproductions of aerial photographs, any geometric inaccuracies in the original photograph are carried over into the digital products.
EarthExplorer offers the entire NAPP collection, which includes accepted photography as well as any other frames on the roll of film. To view additional frames on a roll of film in EarthExplorer, set up a search for your area of interest then select the “View Entire Roll” () icon by one of the images on the results page. Images have been captured as they appear on the roll of film and may need to be rotated to adjust the orientation.
Digital Products
EarthExplorer offers medium and high resolution digital products for the National Aerial Photography Program (NAPP) collection. The files are stored in Tagged Image File Format (TIFF).
Medium Resolution Digital NAPP Products were created with a digital single-lens reflex camera at a resolution of 63 microns, or 400 dots per inch (dpi). These products can be downloaded through EarthExplorer at no cost.
High Resolution Digital NAPP Products were created with digital scanning back systems at a resolution of 25 microns, or 1,000 dpi. These products can be downloaded through EarthExplorer at no cost.
The USGS Film Archive is being systematically scanned at a resolution of 25 microns beginning with film sources that are affected by vinegar syndrome degradation. High resolution scans of NAPP photography will be offered to the public at no charge after the work has been completed for older photography. USGS EROS is currently offering on-demand scanning services for NAPP photography to meet customer requirements for high resolution scanned images.
On-demand scanning is available for NAPP film sources that are held in the USGS EROS film archive. EarthExplorer has an ‘Order Scene’ icon () on the results page for images that are available for photogrammetric quality scanning. Black and White (BW) images are scanned at 7 microns (3,600 dpi). Color images are scanned at 14-micron due to file size. On-demand film scans for NAPP Records are not archived in the USGS EROS database and are not available for download through EarthExplorer.
On-demand film scans are not archived in the USGS EROS database and are not available for download through EarthExplorer.
| Image Parameters | |||
|---|---|---|---|
| Product Type | Micron Size | BW File Size | Color File Size |
| Medium Resolution Download | 63 Micron | 15 MB | 45 MB |
| High Resolution Download* | 25 Micron | 120 MB | 360 MB |
| On-Demand Film Scan | 14 Micron | Not Available | 780 MB |
| On-Demand Film Scan | 7 Micron | 1 GB | Not Available |
*Standard products are created with a digital scanning back.
Prices
Medium resolution and existing High Resolution Film Scan digital images are available for download at no cost.
On-demand high resolution film scans are available for $30.00 per frame. A $5.00 handling fee is charged for all orders requiring payment.
Coverage Maps
Coverage Maps indicating the availability of NAPP products are available for download.
Additional Information
Access Data
EarthExplorer can be used to search, preview, and download existing medium resolution digital files at no cost. Existing High Resolution Film Scan images are also available for download at no cost.
For all other high resolution imagery, an order will need to be placed in EarthExplorer to scan the film at $30.00 per frame. The collection is located under the Aerial Photography category as NAPP.
In addition, aerial photographic reproductions and digital products for the NAPP collection can be ordered through the USDA Aerial Photography Field Office (APFO)
Digital Object Identifier (DOI)
National Aerial Photography Program (NAPP) Digital Object Identifier (DOI) number: /10.5066/F7VD6WQZ
