Bathymetric and Velocimetric Data from Surveys at Highway Bridges crossing the Missouri and Mississippi Rivers on the Periphery of Missouri, June 2009 through August 2018
February 21, 2020
These data are high-resolution bathymetry (riverbed elevation) and depth-averaged velocities in ASCII format, generated from hydrographic and velocimetric surveys near highway bridge structures over the Missouri and Mississippi Rivers on the periphery of Missouri, for dates ranging from 2008 to 2018. Hydrographic data were collected using a high-resolution multibeam echosounder mapping system (MBMS), which consists of a multibeam echosounder (MBES) and an inertial navigation system (INS) mounted on a marine survey vessel. Data were collected as the vessel traversed the river along planned survey lines distributed throughout the reach. Data collection software integrated and stored the depth data from the MBES and the horizontal and vertical position and attitude data of the vessel from the INS in real time. Data processing required computer software to extract bathymetry data from the raw data files and to summarize and map the information. Velocity data were collected using an acoustic Doppler current profiler (ADCP) mounted on a survey vessel equipped with a differential global positioning system (DGPS). Data were collected as the vessel traversed the river along planned transect lines distributed throughout the reach. Velocity data were processed using the Velocity Mapping Toolbox (Parsons and others, 2013), and smoothed using neighboring nodes.
Citation Information
Publication Year | 2020 |
---|---|
Title | Bathymetric and Velocimetric Data from Surveys at Highway Bridges crossing the Missouri and Mississippi Rivers on the Periphery of Missouri, June 2009 through August 2018 |
DOI | 10.5066/P9WDI9YF |
Authors | Richard J Huizinga |
Product Type | Data Release |
Record Source | USGS Asset Identifier Service (AIS) |
USGS Organization | Central Midwest Water Science Center |
Rights | This work is marked with CC0 1.0 Universal |
