Bathymetric and velocimetric data were collected by the U.S. Geological Survey, in cooperation with the Missouri Department of Transportation, near 7 bridges at 6 highway crossings of the Missouri and Mississippi Rivers on the periphery of the State of Missouri from July 16 to August 13, 2018. A multibeam echosounder mapping system was used to obtain channel-bed elevations for river reaches about 1,640 feet longitudinally and generally extending laterally across the active channel from bank to bank during moderate flood-flow conditions. These surveys indicate the channel conditions at the time of the surveys and provide characteristics of scour holes that may be useful in the development of predictive guidelines or equations for scour holes. These data also may be useful to the Missouri Department of Transportation as a low to moderate flood-flow comparison to help assess the bridges for stability and integrity issues with respect to bridge scour during floods.
Bathymetric data were collected around every pier that was in water, except those at the edge of water, and scour holes were present at most piers for which bathymetry could be obtained, except those on banks, on bedrock, or surrounded by riprap. Occasionally, the scour hole near a pier was difficult to discern from nearby bed features. The observed scour holes at the surveyed bridges were generally examined with respect to shape and depth.
Although partial exposure of substructural support elements was observed at several piers, at most sites the exposure likely can be considered minimal compared to the overall substructure that remains buried in bed material at these piers. The notable exceptions are piers 12 and 13 at structure L0135 on State Highway 51 at Chester, Illinois, at which the bedrock material was fully exposed around the piers.
The presence of riprap blankets, pier size and nose shape, and alignment to flow had a substantial effect on the size of the scour hole observed for a given pier. Piers that were surrounded by riprap blankets had scour holes that were substantially smaller (to nonexistent) compared to piers at which no rock or riprap were present. Narrow piers having round or sharp noses that were aligned with flow often had scour holes that were difficult to discern from nearby bed features, whereas piers having wide or blunt noses resulted in larger, deeper scour holes. Several of the structures had piers that were skewed to primary approach flow, and scour holes near these piers generally displayed deposition on the leeward side of the pier and greater depth on the side of the pier with impinging flow.
|Title||Bathymetric and velocimetric surveys at highway bridges crossing the Missouri and Mississippi Rivers on the periphery of Missouri, July–August 2018|
|Authors||Richard J. Huizinga|
|Publication Subtype||USGS Numbered Series|
|Series Title||Scientific Investigations Report|
|Record Source||USGS Publications Warehouse|
|USGS Organization||Central Midwest Water Science Center|
Bathymetric and Velocimetric Data from Surveys at Highway Bridges crossing the Missouri and Mississippi Rivers on the Periphery of Missouri, June 2009 through August 2018
Richard J Huizinga
Bathymetric and Velocimetric Data from Surveys at Highway Bridges crossing the Missouri and Mississippi Rivers on the Periphery of Missouri, June 2009 through August 2018These data are high-resolution bathymetry (riverbed elevation) and depth-averaged velocities in ASCII format, generated from hydrographic and velocimetric surveys near highway bridge structures over the Missouri and Mississippi Rivers on the periphery of Missouri, for dates ranging from 2008 to 2018. Hydrographic data were collected using a high-resolution multibeam echosounder mapping system (MBM
