Geospatial Bathymetry Dataset and elevation-area-capacity tables for Morris Lake (Newton Reservoir), New Jersey, 2018

Morris Lake, also known as Newton Reservoir, has been the source of drinking water for the Town of Newton, New Jersey, since the early 1900s. Although Morris Lake has been used as a source of drinking water for many years, its capacity was previously unknown. In April 2018, the U.S. Geological Survey and the New Jersey Department of Environmental Protection conducted a bathymetric survey of Morris Lake using a multibeam echosounder to map the reservoir. The points measured with the multibeam echosounder were combined with lidar data above the water surface and processed to create a 3.3-foot (1 meter) raster grid of the bathymetric surface, bathymetric contours at 2-foot intervals of depth and elevation, and an elevation-area-capacity table. The results of the bathymetric survey show that Morris Lake has a maximum depth of just over 119 feet with an average depth of 42 feet. Parts of the reservoir, like the surrounding topography, are extremely steep. The capacity of the reservoir at full spillway level is 1,980 million gallons, with a corresponding surface area of 145 acres. The accuracy of the mapped multibeam echosounder bathymetric data was evaluated using a quality assurance dataset collected with a single-beam echosounder: 9,386 quality assurance points were spatially joined with the mapped raster surface to compute measurement errors. The calculated median point error for Morris Lake was 0.23 feet, the median absolute error was 0.35 feet, and the 95-percent accuracy was 2.68 feet. The largest errors occurred in the steepest areas of the reservoir and in unmeasured areas.
