Radar-based field measurements of surface velocity and discharge from 10 U.S. Geological Survey streamgages for various locations in the United States, 2002-19
Near-field remote sensing methods were used to collect Doppler velocity and pulsed stage radar data at 10 conventional U.S. Geological Survey streamgages in river reaches with varying hydrologic and hydraulic characteristics. Basin sizes ranged from 381 to 66,200 square kilometers and included agricultural, desert, forest, mixed, and high-gradient mountain environments. During the siting and operational phases, radar-derived mean-channel (mean) velocity and discharge were computed using the Probability Concept (PC) and were compared against conventional instantaneous measurements and stage-discharge time series. During siting phase, radars were located, installed, and PC parameters computed. To test the efficacy of the remote-sensing methods, radars were deployed for extended periods of time to capture a range of hydraulic conditions. During operational phase, continuous time series of radar-derived surface velocity and discharge and stage-discharge were recorded, computed, and transmitted contemporaneously and continuously in real time every 5 to 15 minutes. Data are presented in two compressed (zipped) folders and one comma-separated value (CSV) file. One folder contains the radar-derived discharge values. One folder contains the stage-discharge values that were used to check the accuracy of radar-derived values. The CSV file contains siting and validation values used to derive the discharge values for the radar time series.
Citation Information
| Publication Year | 2022 |
|---|---|
| Title | Radar-based field measurements of surface velocity and discharge from 10 U.S. Geological Survey streamgages for various locations in the United States, 2002-19 |
| DOI | 10.5066/P98DC3DX |
| Authors | William R Mcdermott, John W Fulton |
| Product Type | Data Release |
| Record Source | USGS Digital Object Identifier Catalog |
| USGS Organization | Colorado Water Science Center - Main Office |
Related Content
Near-field remote sensing of surface velocity and river discharge using radars and the probability concept at 10 USGS streamgages
Related Content
- Publications
Near-field remote sensing of surface velocity and river discharge using radars and the probability concept at 10 USGS streamgages
Near-field remote sensing of surface velocity and river discharge (discharge) were measured using coherent, continuous wave Doppler and pulsed radars. Traditional streamgaging requires sensors be deployed in the water column; however, near-field remote sensing has the potential to transform streamgaging operations through non-contact methods in the U.S. Geological Survey (USGS) and other agenciesAuthorsJohn Fulton, Chris A. Mason, Jack R. Eggleston, Matthew J. Nicotra, C.-L. Chiu, Mark F. Henneberg, Heather Best, Jay Cederberg, Stephen R. Holnbeck, R. Russell Lotspeich, Christopher Laveau, Tommaso Moramarco, Mark E. Jones, Jonathan J Gourley, Danny Wasielewski - Connect
