Topographic and bathymetric data, structure from motion imagery, and ground control data collected at Head of the Meadow Beach, Truro, MA in March 2022, U.S. Geological Survey Field Activity 2022-015-FA

September 19, 2022

These data map the beach and nearshore environment at Head of the Meadow Beach in Truro, MA, providing updated regional context for the 2019 CoastCam installation. CoastCam CACO-01 are two video cameras aimed at the beach that view the coast shared by beachgoers, shorebirds, seals, and sharks. These data were collected as part of field activity 2022-015-FA and a collaboration with the National Park Service at Cape Cod National Seashore to monitor the region. In March 2022, U.S. Geological Survey and Woods Hole Oceanographic Institution (WHOI) scientists conducted field surveys to re-map the field of view of the CoastCam. Aerial images of the beach for use in structure from motion were taken with a camera (Sony a6000) and a post-processed kinematic (PPK) system attached to a helium filled balloon-kite (Helikite). High-precision GPS targets (AeroPoints) and numbered black and white tarps were used as ground control points. Bathymetry was collected in the nearshore using a single-beam echosounder mounted on a surf capable self-righting electric autonomous surface vehicle. Agisoft Metashape (v. 1.8.1) was used to create a digital surface model with the collected imagery, which was merged with the bathymetry in MATLAB (v. 2020b) to create a continuous topobathy product. To cite an indiviudal dataset within the release use the following format example: Over, J.R., Sherwood, C.R., and Traykovski, P.A., 2022, Bathymetric data and grid of offshore Head of the Meadow Beach, Truro, on March 18, 2022 in Topographic and bathymetric data, structure from motion imagery, and ground control data collected at Head of the Meadow Beach, Truro, MA in March 2022, U.S. Geological Survey Field Activity 2022-015-FA: U.S. Geological Survey data release, https://doi.org/10.5066/P9GEVWG1.

Citation Information

Publication Year 2022
Title Topographic and bathymetric data, structure from motion imagery, and ground control data collected at Head of the Meadow Beach, Truro, MA in March 2022, U.S. Geological Survey Field Activity 2022-015-FA
DOI 10.5066/P9GEVWG1
Authors Over Jin-Si R., Sherwood Christopher R, Traykovski Peter
Product Type Data Release
Record Source USGS Digital Object Identifier Catalog
USGS Organization Woods Hole Coastal and Marine Science Center
