Bathymetric contour maps, surface area and capacity tables, and bathymetric change maps for selected water-supply lakes in north-central and west-central Missouri, 2020

May 31, 2023

Bathymetric data were collected at 10 water-supply lakes in north-central and west-central Missouri by the U.S. Geological Survey (USGS) in cooperation with the Missouri Department of Natural Resources and in collaboration with various local agencies, as part of a multiyear effort to establish or update the surface area and capacity tables for the surveyed lakes. The lakes were surveyed in June and July 2020. Seven of the lakes had been surveyed by the USGS between 2002 and 2007, and the recent surveys were compared to the earlier surveys to document changes in the bathymetric surface and capacity of the lake and produce a bathymetric change map.

Bathymetric data were collected using a high-resolution multibeam mapping system mounted on a boat. Supplemental depth data at two of the lakes were collected in shallow areas with an acoustic Doppler current profiler on a remote-controlled boat. Data points from the various sources were exported at a gridded data resolution appropriate to each lake, either 0.82 foot or 1.64 feet. Data outside the multibeam survey extent and greater than the surveyed water-surface elevation generally were obtained from data collected using aerial light detection and ranging (lidar) point cloud data, except at Holden City Lake. A linear enforcement technique was used to add points to the dataset in areas of sparse data (the upper ends of coves where the water was shallow or aquatic vegetation precluded data acquisition) based on surrounding multibeam and upland data values. The various point datasets were used to produce a three-dimensional triangulated irregular network surface of lake-bottom elevations for each lake. A surface area and capacity table was produced from the three-dimensional surface for each lake showing surface area and capacity at specified lake water-surface elevations. Various quality-assurance tests were conducted to ensure quality data were collected with the multibeam, including beam angle checks and patch tests. Additional quality-assurance tests were conducted on the gridded bathymetric data from the survey, the bathymetric surface created from the gridded data, and the contours created from the bathymetric survey.

If data from a previous bathymetric survey existed at a given lake, a bathymetric change map was generated from the elevation difference between the previous survey and the 2020 bathymetric survey data points. After reconciling any vertical datum disagreement between the previous survey and the 2020 survey, coincident points between the surveys were identified, and a bathymetric change map was generated using the coincident point data.

A decrease in capacity was observed at nearly all the lakes for which a previous survey existed, and the mean bathymetric change between the surveys was positive at all the lakes. The decrease in capacity at the primary spillway elevation ranged from –0.4 percent at Edwin A Pape Lake to 9.4 percent at upper Higginsville Reservoir. The mean bathymetric change ranged from 0.03 foot at Garden City New Lake to 1.75 feet at Harrisonville City Lake, which corresponds to a time-averaged mean bathymetric change ranging from 0.002 foot per year at Garden City New Lake to 0.132 foot per year at Harrisonville City Lake. The computed volumetric sedimentation rate generally ranged from 0.04 to 4.91 acre-feet per year at Garden City New Lake and Holden City Lake, respectively; however, Harrisonville City Lake had a substantially larger volumetric sedimentation rate of 42.7 acre-feet per year, corresponding to the substantial mean bathymetric change of 1.75 feet and combined with the relatively shorter interval between surveys. Harrisonville City Lake also had the second-largest decrease in capacity at the spillway elevation of 5.9 percent. As with the 2019 surveys, some changes observed in the bathymetric change maps likely result from the difference in data collection equipment and techniques between the surveys. Certain apparent erosional features around the perimeter of certain lakes may be the result of wave action or compaction of sediments exposed to air during low-water years, or may indicate an unidentified but systemic error in the older singlebeam echosounder survey data.

Publication Year 2023
Title Bathymetric contour maps, surface area and capacity tables, and bathymetric change maps for selected water-supply lakes in north-central and west-central Missouri, 2020
DOI 10.3133/sir20235046
Authors Richard J. Huizinga, Benjamin C. Rivers, Joseph M. Richards, Garett J. Waite
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2023-5046
Index ID sir20235046
Record Source USGS Publications Warehouse
USGS Organization Central Midwest Water Science Center
