Evaluation of an acoustic fish deterrent system in shallow water application at the Emiquon Preserve, Lewistown, IL.

September 1, 2019

Expansion of non-native fish have caused ecological and economic damage and can negatively impact native fish populations. Current research on deterrent technologies for bighead Hypophthalmichthys nobilis and silver carp H. molitrix have primarily focused on reducing upstream movement in large river lock approaches. However, there is also interest in excluding carp from smaller-scale locations. A water control structure at Emiquon Preserve, Lewistown, Illinois, USA reconnected the Preserve’s wetland lakes to the Illinois River, and is a pinch point that site managers seek to deter immigration of non-native fishes without restricting native fish movement. One possible deterrent strategy that was evaluated within the water control structure in 2017 was the use of a 100 hp boat motor acoustic stimulus. Two underwater speakers were installed in each of two culverts to discourage fish movement though the water control structure. Fish passage was monitored using a series of passive integrated transponder (PIT) antennas in a confined study area. A combination of 176 fish consisting of seven different species (native and non-native) were implanted with PIT tags and relocated downstream of the water control structure. Over 2 days of periodic playback of the acoustic stimulus, 29% of tagged silver carp that were detected crossed though the active underwater speaker array. The acoustic treatment did not significantly reduce silver carp or native centrarchid passage through the culverts. However, numerous silver carp were observed jumping out of the acoustically active culvert at the onset of the stimulus. The acoustic stimulus, especially the frequencies to which silver carp are most sensitive to (< 2000 Hz), rapidly attenuated in the water control structure (water depth 0.55–0.38 m). Depth related attenuation observed in and around the water control structure may have reduced the efficacy of the acoustic fish deterrent system at this location.

Citation Information

Publication Year 2019
Title Evaluation of an acoustic fish deterrent system in shallow water application at the Emiquon Preserve, Lewistown, IL.
DOI 10.3391/mbi.2019.10.3.09
Authors James Wamboldt, Kelsie A. Murchy, J.C. Stanton, K. Douglas Blodgett, Marybeth Brey
Publication Type Article
Publication Subtype Journal Article
Series Title Management of Biological Invasions
Series Number
Index ID 70205437
Record Source USGS Publications Warehouse
USGS Organization Upper Midwest Environmental Sciences Center
