Evaluation of sensor types and environmental controls on mapping biomass of coastal marsh emergent vegetation

May 13, 2014

There is a need to quantify large-scale plant productivity in coastal marshes to understand marsh resilience to sea level rise, to help define eligibility for carbon offset credits, and to monitor impacts from land use, eutrophication and contamination. Remote monitoring of aboveground biomass of emergent wetland vegetation will help address this need. Differences in sensor spatial resolution, bandwidth, temporal frequency and cost constrain the accuracy of biomass maps produced for management applications. In addition the use of vegetation indices to map biomass may not be effective in wetlands due to confounding effects of water inundation on spectral reflectance. To address these challenges, we used partial least squares regression to select optimal spectral features in situ and with satellite reflectance data to develop predictive models of aboveground biomass for common emergent freshwater marsh species, Typha spp. and Schoenoplectus acutus, at two restored marshes in the Sacramento–San Joaquin River Delta, California, USA. We used field spectrometer data to test model errors associated with hyperspectral narrowbands and multispectral broadbands, the influence of water inundation on prediction accuracy, and the ability to develop species specific models. We used Hyperion data, Digital Globe World View-2 (WV-2) data, and Landsat 7 data to scale up the best statistical models of biomass. Field spectrometer-based models of the full dataset showed that narrowband reflectance data predicted biomass somewhat, though not significantly better than broadband reflectance data [R2 = 0.46 and percent normalized RMSE (%RMSE) = 16% for narrowband models]. However hyperspectral first derivative reflectance spectra best predicted biomass for plots where water levels were less than 15 cm (R2 = 0.69, %RMSE = 12.6%). In species-specific models, error rates differed by species (Typha spp.: %RMSE = 18.5%; S. acutus: %RMSE = 24.9%), likely due to the more vertical structure and deeper water habitat of S. acutus. The Landsat 7 dataset (7 images) predicted biomass slightly better than the WV-2 dataset (6 images) (R2 = 0.56, %RMSE = 20.9%, compared to R2 = 0.45, RMSE = 21.5%). The Hyperion dataset (one image) was least successful in predicting biomass (R2 = 0.27, %RMSE = 33.5%). Shortwave infrared bands on 30 m-resolution Hyperion and Landsat 7 sensors aided biomass estimation; however managers need to weigh tradeoffs between cost, additional spectral information, and high spatial resolution that will identify variability in small, fragmented marshes common to the Sacramento–San Joaquin River Delta and elsewhere in the Western U.S.

Citation Information

Publication Year 2014
Title Evaluation of sensor types and environmental controls on mapping biomass of coastal marsh emergent vegetation
DOI 10.1016/j.rse.2014.04.003
Authors Kristin B. Byrd, Jessica L. O'Connell, Stefania Di Tommaso, Maggi Kelly
Publication Type Article
Publication Subtype Journal Article
Series Title Remote Sensing of Environment
Series Number
Index ID 70104213
Record Source USGS Publications Warehouse
USGS Organization Western Geographic Science Center
