USGS EROS Archive - Digital Line Graphs (DLGs) - Intermediate Scale
Digital Line Graphs (DLGs) are digital vector representations of cartographic information derived from USGS maps and related sources.
Intermediate-Scale (1:100,000-scale) DLGs are derived from USGS 30- by 60-minute quadrangle maps and are sold in 30- by 30-minute units that correspond to the east or west half of the topographic quadrangle maps. Each 30-minute unit is produced and distributed as four 15- by 15-minute cells. They are cast to the UTM projection system and are referenced to either NAD27 or NAD83.
Depending on scale, the following layers (or categories of feature type) are available:
| Layer | Feature Type |
|---|---|
| Public Land Survey System (PLSS) | Township, range, and section lines |
| Boundaries (BD) | State, county, city, and other national and State lands such as forests and parks |
| Transportation (TR) | Roads and trails, railroads, pipelines, and transmission lines |
| Hydrography (HY) | Flowing water, standing water, and wetlands |
| Hypsography (HP) | Contours and supplementary spot elevations |
| Non-vegetative features (NV) | Glacial moraine, lava, sand, and gravel |
| Survey control and markers (SM) | Horizontal and vertical monuments (third order or better) |
| Man-made features (MS) | Cultural features, such as buildings, not collected in other data categories |
| Vegetative surface cover (SC) | Woods, scrub, orchards, and vineyards |
Coverage Maps
Coverage Maps indicating the availability of Digital Line Graphs Intermediate-Scale products are available for download.
Additional Information
Access Data
EarthExplorer can be used to search, preview, and, download Digital Line Graph (DLG) data. The collection is located under the Digital Line Graphs category.
Digital Object Identifier (DOI)
