The USGS is using a set of advanced imaging and analysis tools to study the rocks within the eastern Adirondacks of upstate New York. The goal of these studies is to gain a better understanding of the geology and mineral resources in the area.
Science Issue and Relevance
Iron mining was common in the Eastern Adirondacks in the late 1800s and early 1900s, but the area also contains deposits of rare earth minerals. These elements are used in mobile devices, rechargeable batteries, super-magnets, solar panels and other advanced technologies. In some parts of the Adirondacks these minerals can be found in the discards or tailings from earlier iron and titanium mines.
The USGS is using a set of advanced imaging and analysis tools to study the rocks within the eastern Adirondacks of upstate New York. A combination of geophysical, geochemical, mineralogical, geochronological and mapping approaches is being applied. Geophysical methods help with imaging rock types buried beneath vegetation, soil or other rocks while geochemical, mineralogical and mapping studies are used to determine how rare earth elements and other commodities are distributed within those rocks. Combining these results with geochronological data will help us to understand the tectonic and magmatic history of the region and how the ore deposits formed more than a billion years ago.
Methodology to Address Issue
Geophysical Studies: Geophysical data can used to image buried rocks from depths just beneath trees and grass to several miles beneath Earth’s surface. Some methods work via measurements of subtle variations in Earth’s magnetic field or gravitational pull. When rocks with different magnetic properties are juxtaposed next to each other, such as an iron-rich gabbro and a quartz sandstone, they generate subtle differences in Earth’s magnetic field that can be detected. In a similar manner, rocks with different densities can generate subtle but measurable variations in Earth’s gravitational pull.
Radiometric methods use special sensors made with sodium iodide or bismuth to detect and measure the energy of naturally occurring gamma particles. Once the energy spectrum is known, relative amounts of potassium, thorium and uranium in rocks within about 1 meter of Earth’s surface can be estimated.
In December 2015, the USGS contracted high-resolution airborne surveys using magnetic and radiometric methods to image rocks buried beneath vegetation, soil, and other rocks in an area west of Lake Champlain. These data are available at ScienceBase.gov.
Geochemical and Mineralogical Studies: The iron, titanium, and rare earth element (REE) minerals in the eastern Adirondacks are all components of “iron-oxide apatite” (IOA) mineral deposits. Samples from these deposits and mine tailings will be analyzed for geochemistry and mineralogy using tools such as a scanning electron microprobe (SEM) or a petrographic microscope. These data will help determine the distribution of rare earth elements and co-commodities in the area. Valuable heavy rare earth elements such as terbium and dysprosium (used in advanced electronics) are of particular interest, and have been detected in the region.
Geochronological Studies: The ages of rocks in the study area are being determined by using the mineral zircon, which is often present in trace quantities. Zircon grains are particularly useful for dating studies because they are resistant to alteration by weathering processes, even over millions of years. Zircons can thus record multiple episodes of tectonic or magmatic activity. These episodes appear as layers within a single grain. For example, a zircon grain can have an igneous core (created during magmatism) that is surrounded by dark rims (reflecting rock metamorphism, which is often associated with tectonic events). A scanning electron microscope is used to image the zircon layers. The layers are then dated using a SHRIMP (sensitive high resolution ion microprobe) and applying U-Pb geochronology methods. The SHRIMP has an analytical spot size of 20-30 microns, about one-quarter of the diameter of a human hair.
From these efforts, the history of tectonism, magmatism, and ore deposit formation will be better understood. This in turn will help us understand geologic features and ore formation at other iron-oxide-apatite deposits worldwide.
Further Reading
Geology and mineral resources of the eastern Adirondacks
- Fisher, D.W., Isachsen, Y.W., and Rickard, L.V., 1970, Geologic map of New York State, 1970: 1:250,000. Consists of five sheets: Niagara, Finger Lakes, Hudson-Mohawk, Adirondack, and Lower Hudson: Map and Chart Series No. 15, 5 geologic bedrock maps, scale 1:250,000.
- Lupulescu, M.V., Price, J.D., and Chiarenzelli, J.R., 2012, Rare-earth-element (REE) and yttrium mineral potential of New York, in Contributed Papers in Specimen Mineralogy: 38th Rochester Mineralogical Symposium Abstracts: Part 3, Rocks & Minerals, v. 87, no. 5, p. 444-454. doi: 10.1080/00357529.2012.716338
- Lupulescu, M., 2008, Minerals from the iron deposits of New York State: Rocks and Minerals, v. 83, no. 3, p. 248-266, doi: 10.3200/RMIN.83.3.248-266.
- McKeown, F.A. and Klemic, H., 1956, Rare-earth-bearing apatite at Mineville Essex County New York, U.S. Geophysical Survey Billetin 1046-B, p. 9-23, https://pubs.er.usgs.gov/publication/b1046B.
- McLelland, J.M., Selleck, B.W., and Bickford, M.E., 2013, Tectonic evolution of the Adirondack Mountains and Grenville Orogen inliers within the USA: Geoscience Canada, v. 40, p. 318-352. doi: 10.12789/geocanj.2013.40.022
- Valley, P.M., Hanchar, J.M., and Whitehouse, M.J., 2011, New insights on the evolution of the Lyon Mountain Granite and associated Kiruna-type magnetite-apatite deposits, Adirondack Mountains, New York State: Geosphere, v. 7, no. 2, p. 357–389. doi: 10.1130/GES00624.1
Rare earth minerals
- Long, K.R., Van Gosen, B.S., Foley, N.K., and Cordier, Daniel, 2010, The principal rare earth elements deposits of the United States—A summary of domestic deposits and a global perspective: U.S. Geological Survey Scientific Investigations Report 2010–5220, 96 p., https://pubs.usgs.gov/sir/2010/5220/.
- Mariano, A.N., and Mariano, Anthony, Jr., 2012, Rare earth mining and exploration in North America, Elements, v. 8, no. 5, p. 369-376. doi: 10.2113/gselements.8.5.369
Below are data releases associated with this project.
Principal facts of gravity data collected in and around the eastern Adirondack highlands, northern New York
Electron microprobe geochemistry of apatite crystals in the iron oxide-apatite ores of the Adirondack Mountains, New York, 2016-2017
Geochemistry of ore, host rock, and mine waste pile samples of iron oxide-apatite (IOA) deposits of the eastern Adirondack Highlands, New York, in relation to potential rare earth elements resources, 2016-2018
Airborne Geophysical Surveys over the Eastern Adirondacks, New York State
Below are publications associated with this project.
Integrated geophysical imaging of rare-earth-element-bearing iron oxide-apatite deposits in the eastern Adirondack Highlands, New York
Geochemistry and geophysics of iron oxide-apatite deposits and associated waste piles with implications for potential rare earth element resources from ore and historic mine waste in the eastern Adirondack Highlands, New York, USA
Below are news stories associated with this project.
In addition to the USGS National Cooperative Geologic Mapping Program, below are partners associated with this project.
- Overview
The USGS is using a set of advanced imaging and analysis tools to study the rocks within the eastern Adirondacks of upstate New York. The goal of these studies is to gain a better understanding of the geology and mineral resources in the area.
The dark rock below the contact is a vein of magnetite. The magnetic properties of this rock are so strong that a pencil magnet is deflected off vertical. (Credit: Anjana Shah, USGS. Public domain.) Science Issue and Relevance
Iron mining was common in the Eastern Adirondacks in the late 1800s and early 1900s, but the area also contains deposits of rare earth minerals. These elements are used in mobile devices, rechargeable batteries, super-magnets, solar panels and other advanced technologies. In some parts of the Adirondacks these minerals can be found in the discards or tailings from earlier iron and titanium mines.
The USGS is using a set of advanced imaging and analysis tools to study the rocks within the eastern Adirondacks of upstate New York. A combination of geophysical, geochemical, mineralogical, geochronological and mapping approaches is being applied. Geophysical methods help with imaging rock types buried beneath vegetation, soil or other rocks while geochemical, mineralogical and mapping studies are used to determine how rare earth elements and other commodities are distributed within those rocks. Combining these results with geochronological data will help us to understand the tectonic and magmatic history of the region and how the ore deposits formed more than a billion years ago.
Goldak Airborne Surveys used a Cesna Grand Caravan to fly the geophysical surveys. The tail or "stinger" off the back of the plane houses the magnetometer. Having a stinger increases the signal-to-noise ratio of the magnetometer by increasing distance between the sensor and the airplane’s electronics. (Credit: Anjana Shah, USGS. Public domain.) Methodology to Address Issue
Geophysical Studies: Geophysical data can used to image buried rocks from depths just beneath trees and grass to several miles beneath Earth’s surface. Some methods work via measurements of subtle variations in Earth’s magnetic field or gravitational pull. When rocks with different magnetic properties are juxtaposed next to each other, such as an iron-rich gabbro and a quartz sandstone, they generate subtle differences in Earth’s magnetic field that can be detected. In a similar manner, rocks with different densities can generate subtle but measurable variations in Earth’s gravitational pull.
Radiometric methods use special sensors made with sodium iodide or bismuth to detect and measure the energy of naturally occurring gamma particles. Once the energy spectrum is known, relative amounts of potassium, thorium and uranium in rocks within about 1 meter of Earth’s surface can be estimated.
USGS geophysicist Anjana Shah taking a magnetic susceptibility reading at a rock outcrop. (Credit: Greg Walsh, USGS. Public domain.) In December 2015, the USGS contracted high-resolution airborne surveys using magnetic and radiometric methods to image rocks buried beneath vegetation, soil, and other rocks in an area west of Lake Champlain. These data are available at ScienceBase.gov.
Geochemical and Mineralogical Studies: The iron, titanium, and rare earth element (REE) minerals in the eastern Adirondacks are all components of “iron-oxide apatite” (IOA) mineral deposits. Samples from these deposits and mine tailings will be analyzed for geochemistry and mineralogy using tools such as a scanning electron microprobe (SEM) or a petrographic microscope. These data will help determine the distribution of rare earth elements and co-commodities in the area. Valuable heavy rare earth elements such as terbium and dysprosium (used in advanced electronics) are of particular interest, and have been detected in the region.
Geochronological Studies: The ages of rocks in the study area are being determined by using the mineral zircon, which is often present in trace quantities. Zircon grains are particularly useful for dating studies because they are resistant to alteration by weathering processes, even over millions of years. Zircons can thus record multiple episodes of tectonic or magmatic activity. These episodes appear as layers within a single grain. For example, a zircon grain can have an igneous core (created during magmatism) that is surrounded by dark rims (reflecting rock metamorphism, which is often associated with tectonic events). A scanning electron microscope is used to image the zircon layers. The layers are then dated using a SHRIMP (sensitive high resolution ion microprobe) and applying U-Pb geochronology methods. The SHRIMP has an analytical spot size of 20-30 microns, about one-quarter of the diameter of a human hair.
From these efforts, the history of tectonism, magmatism, and ore deposit formation will be better understood. This in turn will help us understand geologic features and ore formation at other iron-oxide-apatite deposits worldwide.
Zircon grains from a quartz-albite rock in Hammondville, NY. The grains were hand-picked from the rock, embedded in epoxy, ground to about half-thickness, and polished. Left: petrographic microscope transmitted light image showing cracks, inclusions, and age “zones” throughout the grains. Right: SEM (scanning electron microprobe) cathodoluminescence showing zones with different trace element compositions, which, in this case, correspond to differences in age. The cores and rims of the zircon grain reflect magmatic and tectonic events that occurred within the region about 1-1.15 billion years ago. Images by John Aleinikoff, USGS. (Public domain.) The bare hill in the background is gravel derived from mine tailings, Eastern Adirondacks, NY. (Credit: Anjana Shah, USGS. Public domain.) Further Reading
Geology and mineral resources of the eastern Adirondacks
- Fisher, D.W., Isachsen, Y.W., and Rickard, L.V., 1970, Geologic map of New York State, 1970: 1:250,000. Consists of five sheets: Niagara, Finger Lakes, Hudson-Mohawk, Adirondack, and Lower Hudson: Map and Chart Series No. 15, 5 geologic bedrock maps, scale 1:250,000.
- Lupulescu, M.V., Price, J.D., and Chiarenzelli, J.R., 2012, Rare-earth-element (REE) and yttrium mineral potential of New York, in Contributed Papers in Specimen Mineralogy: 38th Rochester Mineralogical Symposium Abstracts: Part 3, Rocks & Minerals, v. 87, no. 5, p. 444-454. doi: 10.1080/00357529.2012.716338
- Lupulescu, M., 2008, Minerals from the iron deposits of New York State: Rocks and Minerals, v. 83, no. 3, p. 248-266, doi: 10.3200/RMIN.83.3.248-266.
- McKeown, F.A. and Klemic, H., 1956, Rare-earth-bearing apatite at Mineville Essex County New York, U.S. Geophysical Survey Billetin 1046-B, p. 9-23, https://pubs.er.usgs.gov/publication/b1046B.
- McLelland, J.M., Selleck, B.W., and Bickford, M.E., 2013, Tectonic evolution of the Adirondack Mountains and Grenville Orogen inliers within the USA: Geoscience Canada, v. 40, p. 318-352. doi: 10.12789/geocanj.2013.40.022
- Valley, P.M., Hanchar, J.M., and Whitehouse, M.J., 2011, New insights on the evolution of the Lyon Mountain Granite and associated Kiruna-type magnetite-apatite deposits, Adirondack Mountains, New York State: Geosphere, v. 7, no. 2, p. 357–389. doi: 10.1130/GES00624.1
Rare earth minerals
- Long, K.R., Van Gosen, B.S., Foley, N.K., and Cordier, Daniel, 2010, The principal rare earth elements deposits of the United States—A summary of domestic deposits and a global perspective: U.S. Geological Survey Scientific Investigations Report 2010–5220, 96 p., https://pubs.usgs.gov/sir/2010/5220/.
- Mariano, A.N., and Mariano, Anthony, Jr., 2012, Rare earth mining and exploration in North America, Elements, v. 8, no. 5, p. 369-376. doi: 10.2113/gselements.8.5.369
Lake in the Eastern Adirondacks, New York. (Credit: Anjana Shah, USGS. Public domain.) Scientists in the field in the eastern Adirondacks. From left: Peter Valley (SUNY Potsdam), Marian Lupulescu (NYSGS), John Aleinikoff (USGS), Cliff Taylor (USGS), Ryan Taylor (USGS), Greg Walsh (USGS), and Anjana Shah (USGS). (Credit: Anjana Shah, USGS. Public domain.) - Data
Below are data releases associated with this project.
Principal facts of gravity data collected in and around the eastern Adirondack highlands, northern New York
Gravity data were collected in 2016 and 2017 to assist in mapping subsurface geology in and around the eastern Adirondack highlands, northern New York, which host numerous iron-oxide apatite deposits. Many of these deposits contain rare-earth elements, which are considered a critical mineral resource. This data release provides principal facts for 189 new gravity stations that were acquired to filElectron microprobe geochemistry of apatite crystals in the iron oxide-apatite ores of the Adirondack Mountains, New York, 2016-2017
The iron oxide-apatite (IOA) deposits near Mineville in the Adirondack Mountains, New York, have been of interest for their rich magnetite ore since the mid-1700s but have attracted renewed attention due to their potential as rare earth element (REE) resources (McKeown and Klemic, 1956; Lupulescu and others, 2016; Taylor and others, 2018). Apatite is the main REE-host and is found in variable conGeochemistry of ore, host rock, and mine waste pile samples of iron oxide-apatite (IOA) deposits of the eastern Adirondack Highlands, New York, in relation to potential rare earth elements resources, 2016-2018
Thirty-four ore, twenty-nine mine waste, seven host rock, two pegmatite, and one slag sample were collected from iron oxide-apatite (IOA) mines in the eastern Adirondack Highlands near Mineville and Ticonderoga, New York, from March 2016 to August 2018. The waste pile samples included twenty-five samples collected from rubble-sized mine waste piles and four samples from processed tailings piles.Airborne Geophysical Surveys over the Eastern Adirondacks, New York State
Airborne geophysical surveys were conducted in the eastern Adirondacks from Dec. 7, 2015 - Dec. 21, 2015, by Goldak Airborne Surveys. The area was flown along a draped surface with a nominal survey height above ground of 200 meters. The flight line spacing was 250 meters for traverse lines and 2500 meters for control lines. Here we present downloadable magnetic and radiometric (gamma spectrometry) - Publications
Below are publications associated with this project.
Integrated geophysical imaging of rare-earth-element-bearing iron oxide-apatite deposits in the eastern Adirondack Highlands, New York
The eastern Adirondack Highlands of northern New York host dozens of iron oxide-apatite (IOA) deposits containing magnetite and rare earth element (REE)-bearing apatite. We use new aeromagnetic, aeroradiometric, ground gravity, and sample petrophysical and geochemical data to image and understand these deposits and their geologic framework. Aeromagnetic total field data reflect highly magnetic leuAuthorsAnjana K. Shah, Ryan D. Taylor, Gregory J. Walsh, Jeffrey PhillipsGeochemistry and geophysics of iron oxide-apatite deposits and associated waste piles with implications for potential rare earth element resources from ore and historic mine waste in the eastern Adirondack Highlands, New York, USA
The iron oxide-apatite (IOA) deposits of the eastern Adirondack Highlands, New York, are historical high-grade magnetite mines that contain variable concentrations of rare earth element (REE)-bearing apatite crystals. The majority of the deposits are hosted within sodically altered Lyon Mountain granite gneiss, although some deposits occur within paragneiss, gabbro, anorthosite, or potassically alAuthorsRyan Taylor, Anjana K. Shah, Gregory J. Walsh, Cliff D. Taylor - News
