Prospect- and Mine-Related Features from U.S. Geological Survey 7.5- and 15-Minute Topographic Quadrangle Maps for the Western United States

August 3, 2016

This data release has been updated in 2017 with a newer version that includes additional states.

It is recommended to use the updated data and map services of the new data release located at:

These data are part of a larger USGS project to develop an updated geospatial database of mines, mineral deposits and mineral regions in the United States. Mine and prospect-related symbols, such as those used to represent prospect pits, mines, adits, dumps, tailings, etc., hereafter referred to as mine symbols or features, are currently being digitized on a state-by-state basis from the 7.5-minute (1:24, 000-scale) and the 15-minute (1:48, 000 and 1:62,500-scale) archive of the USGS Historical Topographic Maps Collection, or acquired from available databases (California and Nevada, 1:24,000-scale only). Compilation of these features is the first phase in capturing accurate locations and general information about features related to mineral resource exploration and extraction across the U.S. To date, the compilation of 400,000-plus point and polygon mine symbols from approximately 51,000 maps of 17 western states (AZ, CA, CO,ID, KS, MT, ND, NE, NM, NV, OK, OR, SD, UT, WA, WY and western TX) has been completed. The process renders not only a more complete picture of exploration and mining in the western U.S., but an approximate time line of when these activities occurred. The data may be used for land use planning, assessing abandoned mine lands and mine-related environmental impacts, assessing the value of mineral resources from Federal, State and private lands, and mapping mineralized areas and systems for input into the land management process. The data are presented as three groups of layers based on the scale of the source maps. No reconciliation between the data groups was done.
