Drilling Rig Feeding Pipe into the Borehole for the West Point Extensometer
Detailed Description
In order to construct the borehole extensometer at West Point, 1420 feet of 7 inch steel casing was fed into the ground using the drilling rig, as pictured here. This steel casing allows the borehole to hold its shape and not collapse in on itself, and isolates the 2 inch thick extensometer rod from the surrounding sediments.
Sources/Usage
Public Domain.
