An automated geographic information system-based hydraulic modeling tool for developing preliminary culvert designs for stream crossings in Massachusetts

Introduction

Currently (2026), many of the about 25,000 roadway crossing structures over rivers and streams in Massachusetts are undersized. Undersized culverts and bridges can be detrimental to fish and wildlife movement, habitat continuity, and the health of aquatic organisms. Undersized culverts also can lack the resiliency needed to withstand large floods, which could be worsened by potential increases in flood magnitude and frequency due to climate change. Improving culvert and bridge designs for stream crossing projects may improve aquatic organism passage, stream continuity, and resiliency during future floods by decreasing upstream overbank flooding, road flooding and erosion, and degradation of aquatic habitat.

The U.S. Geological Survey (USGS), Massachusetts Department of Environmental Protection (MassDEP), and University of Massachusetts Amherst began a series of cooperative studies in July 2019 to develop an automated geographic information system (GIS) hydraulic modeling tool for preliminary culvert designs for stream crossings. The USGS plans to provide preliminary culvert designs in the web-based StreamStats application, which enables municipalities and engineers to view potential designs and related information for stream crossing replacement projects in Massachusetts. This application can (a) provide information on hydrology, hydraulics, and ecological conditions at stream crossing sites, (b) provide users with potential culvert designs to improve aquatic organism passage and flood resiliency, and (c) assist MassDEP in implementing the Massachusetts Wetlands Protection Act regulations for stream crossing projects.
