Completion summary for monitor wells NRF-17 and NRF-18 at the Naval Reactors Facility, Idaho National Laboratory, Idaho

The U.S. Geological Survey (USGS)—in cooperation with the U.S. Department of Energy (DOE) for the Naval Reactors Laboratory Field Office that supports operations for the Naval Reactors Facility (NRF) located at the Idaho National Laboratory (INL)—drilled and constructed well NRF-17 (formerly borehole USGS 151) and well NRF-18 (formerly borehole USGS 152) for stratigraphic framework analyses and water-quality monitoring at the Idaho National Laboratory (INL) near the NRF, in southeastern Idaho. Borehole USGS 151 was continuously cored from about 48 to 1,070 feet (ft) below land surface (BLS); rotary drilled from approximately 1,070 to 1,720 ft BLS; and re-drilled to complete construction as a monitor well NRF-17, completed to 461 ft BLS. Borehole USGS 152 was continuously cored from approximately 19 to 1,259 ft BLS; rotary drilled from approximately 1,259 to 1,630 ft BLS; and re-drilled to complete construction as a monitor well NRF-18, completed to 450 ft BLS.

Geophysical data were examined with photographed core material to record lithologic descriptions and to suggest zones where groundwater flow was anticipated. Basalt flows varied from highly fractured to dense, with high-to-low vesiculation. Well NRF-17 generally was constructed in mostly dense basalt (greater than 75 percent), and well NRF-18 was constructed in primarily fractured and (or) vesicular basalt. In well NRF-17, the well capacity is directly affected by the limited amount of fractured basalt, which serves as the primary pathway for groundwater. This effect was observed during the pumping test conducted after the well's final construction.

Single-well aquifer tests were done at wells NRF-17 and NRF-18 to provide estimates of transmissivity and hydraulic conductivity after final well construction and initial well development. Estimated values of transmissivity and hydraulic conductivity for well NRF-17 were 8.81 feet squared per day (ft2/d) and 1.04×10-2 feet per day (ft/d), respectively. Estimated values of transmissivity and hydraulic conductivity for well NRF-18 were 4.77×103 ft²/d and 5.61 ft/d, respectively. The NRF-17 pump test resulted in 19.41 ft of measured drawdown at a sustained average pumping rate of 3.3 gallons per minute (gal/min). The NRF-18 pump test resulted in 0.55 ft of measured drawdown at a sustained average pumping rate of 31.0 gal/min.

Water-quality samples collected from the two wells were analyzed for cations, anions, metals, nutrients, volatile organic compounds, stable isotopes, and radionuclides. Water samples for select inorganic constituents showed concentrations consistent with signatures from tributary valley groundwater with influences from ephemeral surface-water recharge from the Big Lost River. Water-quality samples analyzed for stable isotopes of oxygen and hydrogen are consistent with signatures from tributary valley groundwater and surface-water recharge inputs to the aquifer. No measured water-quality results were greater than their respective maximum contaminant levels for public drinking-water supplies. Inorganic and nutrient water-quality results for well NRF-17 and well NRF-18 suggest the groundwater in this area is potentially affected by industrial wastewater disposal.
