Development of a two-dimensional hydraulic model for the Kalamazoo River between the Trowbridge and Allegan City Dams, Michigan

The U.S. Geological Survey developed a two-dimensional hydraulic model for a 9.2-mile reach of the Kalamazoo River between the Trowbridge and Allegan City Dams. The model simulates streamflow conditions with spatial coverage and resolution that would be difficult or dangerous to document with field measurements, enabling assessments of habitat connectivity and substrate stability to support dam removal and restoration planning. The model was calibrated with surveyed water surface elevation (WSE) profiles, streamgage WSE time series, and measured depth-average velocities. Modeled WSE profiles had root mean square error (RMSE) values of 0.20 and 0.32 foot. Cross-sectional average velocities were slightly underpredicted, with RMSE of 0.28 and 0.30 foot per second (ft/s). Channel roughness varied with stage, and the high-flow model reproduced streamgage WSE time series with an RMSE of 0.04 foot. Quasi-steady simulations at 4,000 cubic feet per second (ft³/s), about the 50-percent annual exceedance probability streamflow, indicated that cross-sectional average velocities within 3.4 miles downstream from Trowbridge Dam were commonly between 3 and 4 ft/s, occasionally exceeding 4 ft/s. Farther downstream, velocities seldom exceeded 3 ft/s. Simulated shear stresses were used to estimate substrate stability in the reach. At 4,000 ft³/s, the minimum stable grain size along most of the main channel was predicted to be in the pebble range (4–64 millimeters), and sands and silts were predicted to be stable in the floodplain and backwaters.
