Geophysical and Other Data From an Irrigation Monitoring Experiment at Haddam Meadows, CT, July 2019

October 21, 2022

An irrigation monitoring experiment was performed in Haddam Meadows State Park, Connecticut, on July 16, 2019. Prior to this experiment, ground penetrating radar (GPR), frequency domain electromagnetics (FDEM), and electrical resistivity tomography (ERT) geophysical data were collected over a 20 meter by 10-meter grid to provide baseline information. A vertical soil moisture probe was installed in the center of this area that recorded volumetric water content, temperature, and electrical conductivity at 9 discrete depths down to 1 meter below land surface. Over the next 8 hours, 5,300 liters of irrigation water (with specific conductance of 1,000 microSiemens per centimeter) was sprayed as evenly as practical over an 8 meter by 3-meter area in the center of the study grid. During this time, 3 ERT datasets were collected. At the end of the experiment, another ERT dataset was collected, as well as a final GPR and FDEM data grid. Finally, a push-style probe was used to gather post-irrigation soil moisture conditions from several points and depths (maximum of 0.75 meters below land surface) within the study grid (62 total data points were collected).

Citation Information

Publication Year 2022
Title Geophysical and Other Data From an Irrigation Monitoring Experiment at Haddam Meadows, CT, July 2019
DOI 10.5066/P9N9IY4C
Authors Neil C Terry, Eric A White, John W Lane, Martin Briggs, Carole D Johnson
Product Type Data Release
Record Source USGS Digital Object Identifier Catalog
USGS Organization New York Water Science Center
