Geophysical log analysis of selected test and residential wells at the Shenandoah Road National Superfund Site, East Fishkill, Dutchess County, New York

March 20, 2015

The U.S. Geological Survey collected and analyzed geophysical logs from 20 test wells and 23 residential wells at the Shenandoah Road National Superfund Site in East Fishkill, New York, from 2006 through 2010 as part of an Interagency Agreement to provide hydrogeologic technical support to the U.S. Environmental Protection Agency, Region 2. The geophysical logs collected include caliper, gamma, acoustic and optical televiewer, deviation, electromagnetic-induction, magnetic-susceptibility, fluid-property, and flow under ambient and pumped conditions. The geophysical logs were analyzed along with single-well aquifer test data and drilling logs to characterize the lithology, fabric, fractures, and flow zones penetrated by the wells. The results of the geophysical log analysis were used as part of the hydrogeologic characterization of the site and in the design of discrete-zone monitoring installations in the test wells and selected residential wells.

Most of the logged test and residential wells penetrated gneiss of the Hudson Highlands Complex or dolostones in the Wappinger Group, and some wells penetrated both the dolostone and gneiss. The bedrock fabric reflects the regional northeast-southwest structural trend, as well as localized folding, and includes foliation in the gneiss and bedding in the dolostone. Many fractures were oriented along the bedrock fabric, whereas others were orthogonal to the fabric.

Total wellbore transmissivity of the wells was estimated from short-term, single-well aquifer test data through the use of the Cooper-Jacob analytical solution. An empirical relation was established to estimate total wellbore transmissivity from specific-capacity data for wells with insufficient transient drawdown measurements. Wellbore transmissivity estimates ranged from 0.36 to 370 feet squared per day (ft2/d), whereas specific capacities ranged from 0.03 to 2.1 gallons per minute per foot ((gal/min)/ft).

Transmissivity and hydraulic heads of individual fracture zones were estimated from the total wellbore transmissivity and flow logs through use of an analytical model based on the Thiem equation. The model-estimated transmissivity of 95 fracture zones delineated in the 43 wells ranged from 0.25 to 340 ft2/d, with a median value of 6.7 ft2/d. The difference between model-estimated fracture-zone heads and the composite heads in each well ranged from less 0.01 to more than 10 feet (ft). Flow-log analysis generally provided an order of magnitude estimate for the fracture-zone hydraulic-head difference on the basis of a comparison of estimated and measured values.

The geophysical logs and their analyses are available for display and download from the U.S. Geological Survey, New York Water Science Center, online geophysical log archive (http://ny.water.usgs.gov/maps/geologs/) in LAS (Log ASCII Standard), PDF, and WellCad formats.

Publication Year 2015
Title Geophysical log analysis of selected test and residential wells at the Shenandoah Road National Superfund Site, East Fishkill, Dutchess County, New York
DOI 10.3133/sir20145228
Authors Richard J. Reynolds, J. Alton Anderson, John H. Williams
Publication Type Report
Publication Subtype USGS Numbered Series
Series Title Scientific Investigations Report
Series Number 2014-5228
Index ID sir20145228
Record Source USGS Publications Warehouse
USGS Organization New York Water Science Center
