The Aerial Imaging and Mapping group (AIM), at the U.S. Geological Survey Woods (USGS) Hole Coastal and Marine Science Center provides UAS services to scientists to advance the science mission of the Coastal and Marine Geology Program. Scientists at the Woods Hole Coastal and Marine Science Center have been using UASs to acquire imagery of coastal and wetland environments, which is then used to produce detailed topographic and visual reflectance datasets. UAS technology is used to support the work of geologists, engineers, physical scientists, geographers, and geochemists who study coastal erosion, sediment transport and storm response, habitat classification, biomass mapping, and marsh stability.
Unmanned aerial system (UAS) technology provides a rapid and low-cost solution for mapping coastal environments and assessing short- and long-term changes. The interdisciplinary nature of the data collected and the breadth of applications makes UAS technology applicable to multiple scientific investigations.
One of the primary science applications for UASs is mapping. Drones can make accurate maps by combining images, which can be interpolated into three-dimensional imagery with software that utilizes photogrammetric techniques to form orthomosaics and digital surface models. Using control points on the ground, these maps can be produced with horizontal resolutions of 5 to 10 centimeters (cm) and vertical precision within 8 cm, precision is measured compared with independent measurements from global navigation satellite system equipment with real-time kinematic positioning (RTK). The maps created with drone-acquired imagery are comparable in quality with images from light detection and ranging (lidar) surveys with color processing but can be produced at a fraction of the cost.
UAS map products can be used to meet many science objectives, including to quantify geomorphic changes in coastal landscapes, classify landcover and geomorphic features in wetland and riparian landscapes, and assess habitat suitability. UASs can be equipped with multispectral cameras (cameras that capture images within specific ranges across the electromagnetic spectrum) and can be used to classify vegetation or identify invasive species. Other potential applications for UASs include inferring nearshore bathymetry from drone imagery of waves, measuring shallow bathymetry in streams and estuaries, measuring stream or inlet flow using image processing methods or UAS-mounted radar, and making thermal measurements to identify groundwater discharges.
The AIM group at the Woods Hole Coastal and Marine Science Center currently [2018] has five UAS pilots who are certified in accordance with U.S. Department of the Interior (DOI) policies. The center currently has three 3DR Solo quadcopter drones, and a Birds Eye View FireFly6 Pro fixed-wing UAS. Both UASs can be mounted with a Pentax Ricoh GRII natural-color, high-resolution, global shutter camera, a MicaSense Rededge3 multispectral wavelength camera, or a GoPro Hero 4 compact camera. Trimble Spectra Precision SP80 Global Navigation Satellite System receivers are used to precisely geolocate control points at survey areas. Images from drone flights are processed with Agisoft Photoscan software, and Pix4D processing software.
With this equipment, the AIM group can survey a study area of approximately 0.5 to 1 square kilometer (160 acres) per day. Each multiplatform survey requires approximately five people to perform the survey efficiently, including two pilots, two survey crew, and a visual observer and data recorder.
The USGS Woods Hole Coastal and Marine Science Center maintains an ongoing collaboration with scientists and UAS technicians at the USGS National Unmanned Aircraft Systems Project in Denver, Colorado; other institutions, including the Woods Hole Oceanographic Institution; and local UAS operators and contractors. Woods Hole pilots have assisted DOI’s Office of Aviation Services (OAS) in monitoring natural hazard emergencies and have been instructors for OAS-sponsored training classes. This networking and collaboration helps the AIM group remain current in a rapidly evolving technological field.
Below are multimedia items associated with the Aerial Imaging and Mapping project.
Non-tidal pools found in the high marsh area of the Parker River National Wildlife Refuge, Newbury Ma. USGS Woods Hole Coastal and Marine Science Center UAS pilots are stationed in the upper left corner flying the UAS mission at the refuge.
Non-tidal pools found in the high marsh area of the Parker River National Wildlife Refuge, Newbury Ma. USGS Woods Hole Coastal and Marine Science Center UAS pilots are stationed in the upper left corner flying the UAS mission at the refuge.
USGS Woods Hole Coastal and Marine Science Center UAS pilots Emily Sturdivant and Elizabeth Pendleton, teaming up to perform a drone survey taking images to be used for photogrammetry, and ultimately creating marsh surface models.
USGS Woods Hole Coastal and Marine Science Center UAS pilots Emily Sturdivant and Elizabeth Pendleton, teaming up to perform a drone survey taking images to be used for photogrammetry, and ultimately creating marsh surface models.
USGS WHCMSC pilot Elizabeth Pendleton
USGS pilot Sandy Brosnahan and Senate Pro Tempore Marc Pacheco discuss the use of Umanned Aerial Systems (UASs, also known as drones) to collect data in coastal environments.
USGS pilot Sandy Brosnahan and Senate Pro Tempore Marc Pacheco discuss the use of Umanned Aerial Systems (UASs, also known as drones) to collect data in coastal environments.
Aeiral image of Woods Hole, MA taken during the 2017 Woods Hole Science Stroll. The green USGS tent generated a lot of interest and participation from Science Stroll attendees
Aeiral image of Woods Hole, MA taken during the 2017 Woods Hole Science Stroll. The green USGS tent generated a lot of interest and participation from Science Stroll attendees
Woods Hole Coastal and Marine Science Center drone pilot, Emily Sturdivant, lands a drone on target at the 2017 Woods Hole Science Stroll
Woods Hole Coastal and Marine Science Center drone pilot, Emily Sturdivant, lands a drone on target at the 2017 Woods Hole Science Stroll
Woods Hole Coastal and Marine Science Center drone pilot, Emily Sturdivant, provides a demonstration of drone capabilities at the 2017 Woods Hole Science Stroll
Woods Hole Coastal and Marine Science Center drone pilot, Emily Sturdivant, provides a demonstration of drone capabilities at the 2017 Woods Hole Science Stroll
Screen shot of eerial imagery from unmanned aerial systems (UAS) flights over the Lake Ontario shoreline at Braddock Bay, New York, July 10 to 11, 2017
Screen shot of eerial imagery from unmanned aerial systems (UAS) flights over the Lake Ontario shoreline at Braddock Bay, New York, July 10 to 11, 2017
USGS pilot Sandy Brosnahan and Senate Pro Tempore Marc Pacheco discuss the use of Umanned Aerial Systems (UASs, also known as drones) to collect data in coastal environments. Photo credit: Dann Blackwood, USGS.
USGS pilot Sandy Brosnahan and Senate Pro Tempore Marc Pacheco discuss the use of Umanned Aerial Systems (UASs, also known as drones) to collect data in coastal environments. Photo credit: Dann Blackwood, USGS.
Drone footage taken of the Woods Hole Oceanographic facility on the Quissett campus in Woods Hole Ma. This is an example of a tidally restricted marsh system cutoff from tidal flows by the bike path.
Drone footage taken of the Woods Hole Oceanographic facility on the Quissett campus in Woods Hole Ma. This is an example of a tidally restricted marsh system cutoff from tidal flows by the bike path.
FAQ associated with the Aerial Imagine and Mapping group
Yes, approval is required for operating uncrewed aircraft systems (UAS). The USGS receives flight approval from the Federal Aviation Administration prior to every UAS mission. The official document is referred to as a Certificate of Authorization and Waiver. It is the approval process by which the Federal Aviation Administration allows for public agencies to operate UAS in the National Airspace...
