The USGS is evaluating the integration of small unoccupied aircraft systems – sUAS or "drones" – into USGS hydrogeophysical studies.
The small unoccupied aircraft systems (sUAS) sector is advancing rapidly through:
- miniaturization of aircraft and sensors;
- reduction in system purchase costs;
- increased performance, reliability, and stability; and
- easing of FAA flight restrictions.
This combination of factors is enabling increased use of sUAS as accessible, cost-effective, and safe tools for low-altitude deployment of scientific sensors.
Potential Value to Hydrogoelogic Field Studies
Integration of sUAS into groundwater studies will expand USGS capabilities to collect and use hydrologic information to improve our understanding of groundwater availability and quality:
- sUAS operations enable data collection in areas that might otherwise be difficult or impossible to access, such as unstable stream banks.
- Site reconnaissance with sUAS enables field personnel to quickly assess site conditions to inform placement of equipment or location of sampling and monitoring activities.
- sUAS surveys often can be conducted more rapidly than similar data collection on foot, potentially saving time and costs.
- Structure from Motion can generate high-resolution geo-referenced site imagery and 3D elevation models to inform and improve site conceptual, geophysical, and numerical models.
- Automation of georeferenced sUAS flights makes it easy to collect data from multiple sensors along the same transects and to conduct repeat observations of changing conditions over time.
- The lower cost of sUAS operations compared to traditional helicopter and plane surveys allows for collection of airborne data that might otherwise have been economically unfeasible for a given study.
- sUAS surveys can often provide more timely and higher resolution data than satellites.
- Deployment of sensors via sUAS rather than by foot, boat, or traditional aircraft may decrease USGS personnel exposure to hazardous field conditions.
Evaluation and Integration of sUAS
There is significant interest in the application of sUAS-borne scientific sensors to USGS hydrogeologic studies, especially groundwater/surface-water exchange studies. USGS is evaluating the potential for cost-effective, operationally feasible integration of sUAS-borne sensors into USGS hydrogeophysical studies.
Initial efforts are focusing on evaluation and demonstration of hydrogeologic data collection with natural color, multispectral, and thermal imaging sensors on small quadcopters. Longer term efforts include assessment of new and emerging sUAS geophysical sensors, such as ground-penetrating radar for bathymetry.
Policy and Background Information
Sensors and aircraft used by USGS must be approved for use by the USGS UAS Project Office and Department of the Interior (DOI) Office of Aviation Services. USGS remote pilots are carded for operations by the Department of the Interior and certified Remote Pilots under the Federal Aviation Administration's Part 107.
