Thematic Mapper (TM) Level-1 30-meter multispectral data from Landsats 4 and 5. (1982 to 2012)
The Landsat Thematic Mapper (TM) sensor was carried onboard Landsats 4 and 5 from July 1982 to May 2012 with a 16-day repeat cycle, referenced to the Worldwide Reference System-2. Very few images were acquired from November 2011 to May 2012. The satellite began decommissioning activities in January 2013.
Landsat 4-5 TM image data files consist of seven spectral bands (See band designations). The resolution is 30 meters for bands 1 to 7. (Thermal infrared band 6 was collected at 120 meters, but was resampled to 30 meters.) The approximate scene size is 170 km north-south by 183 km east-west (106 mi by 114 mi).
Product Processing Parameters
Most Landsat 4-5 TM scenes are processed through the Level 1 Product Generation System (LPGS), processed to full Precision Terrain correcton with the following parameters applied for Product Type and L1T Terrain Correction* .
|Product Type||Level-1 Corrected|
|Resampling method||Cubic Convolution (CC)|
|Map Projection||UTM – WGS 84
Polar Stereographic for the continent of Antarctica.
|Image Orientation||Map (North Up)|
|Distribution>||HTTPS Download Only|
|Delivery Time||Immediate download.|
Some TM scenes do not have the ground-control or elevation data necessary to perform these corrections. In the cases, the best level of correction is applied. See Landsat Processing Details for details on correction levels.
Specific Level 1T scenes are available for most of the globe under the Global Land Surveys (GLS) collections of 1975, 1990, 2000, 2005, and 2010. These datasets can be found on EarthExplorer or the USGS Global Visualization Viewer (GloVis).
Some TM scenes are processed through National Land Archive Production System (NLAPS).* All Landsat 4 TM scenes were processed through NLAPS prior to April 15, 2009.
Landsat 4-5 TM Collection 1
Landsat Tiers are the inventory structure for Landsat Collection 1 Level-1 data products and are based on data quality and level of processing. All scenes in the Landsat archive are assigned to a Collection category. The purpose of Collection categories is to support rapid and easy identification of suitable scenes for time-series pixel level analysis.
During Collection 1 reprocessing, all Landsat 4-5 TM scenes in the USGS archive are assigned to a specific “Tier”. These data have well-characterized radiometric quality and are cross-calibrated among the different Landsat sensors.
*NLAPS-processed Landsat TM data are not included in the Landsat 4-5 TM Collection 1 archive.
Collection 1 Categories
- Tier 1 (T1) – Contains the highest quality Level-1 Precision Terrain (L1TP) data considered suitable for time-series analysis. The georegistration is consistent and within prescribed tolerances [<12m root mean square error (RMSE)].
- Tier 2 (T2) – Contains L1TP scenes not meeting Tier 1 criteria and all Systematic Terrain (L1GT) and Systematic (L1GS) scenes. Users interested in Tier 2 scenes can evaluate the L1TP RMSE and other properties to determine suitability for use in their applications and studies.
Landsat TM ‘no-Payload Correction’ Data
An estimated 250,000 Landsat 5 Thematic Mapper (TM) scenes acquired between January 1986 and December 1999, originally downlinked to international ground stations, lack the necessary Payload Correction Data (PCD). Until recently, these scenes failed Landsat Level-1 data processing and could not be added to the Landsat data archive. However, as of early February 2018, processing algorithm changes make it possible to process these scenes into the Landsat Collection 1 data archive and available for download from EarthExplorer and USGS Global Visualization Viewer (GloVis). More information on TM No-PCD scenes can be found on What Are No PCD Scenes.
The Landsat Collections page contains additional information about changes applied to Landsat Level-1 data products for Collection 1.
Coverage Maps indicating the availability of Landsat 4-5 TM Collection 1 products are available for download.
- USGS Landsat - Earth Observations Satellites Fact Sheet
- Landsat Homepage
- Landsat FAQs
- Technical Information (Including calibration and definitive ephemeris files)
- Project Documentation
- Landsat Collections
- Landsat 4-5 TM Digital Object Identifier (DOI) number: /10.5066/F7N015TQ
Landsat 4-5 Thematic Mapper (TM) scenes held in the USGS archive can be searched using EarthExplorer, the USGS Global Visualization Viewer (GloVis), or the LandsatLook Viewer. On EarthExplorer, Landsat 4-5 TM scenes can be found under the Landsat menu in the “Landsat Collection 1 Level-1” section, in the “Landsat 4-5 TM C1 Level-1” dataset.
Some Landsat 5 TM scenes outside the United States were collected and archived at International Ground Stations. The Landsat Global Archive Consolidation (LGAC) effort is underway to bring this data back to the USGS archive.
Data is delivered from the USGS only in digital format, with the parameters noted above. There are several commercial firms that may provide data in different formats.
