Societal Issue: Uncertainty related to rupture extent, slip distribution, and recurrence of past subduction megathrust earthquakes in the Pacific Northwest (northern CA, OR, WA, and southern BC) leads to ambiguity in earthquake and tsunami hazard assessments and hinders our ability to prepare for future events.
Overview
The Pacific Northwest is home to the Cascadia Subduction Zone, a 1,300 km-long tectonic boundary between the Juan de Fuca and Gorda oceanic plates to the west and the North America continental plate to the east (Fig. 1). The denser oceanic plates are converging with North America and subducting beneath the western edge of the continent. The interface between upper and lower plates is defined by a large fault, called a megathrust, as well as numerous smaller faults that cut through the surrounding crust (Fig. 2). Over time, frictional stresses accumulate along these faults, building slowly until they exceed the fault’s strength, resulting in an earthquake. Subduction zone earthquakes are the largest on Earth, reaching magnitudes in excess of magnitude M9, and are known to generate large tsunamis.
As part of a broader collaborative effort within the USGS (Gomberg and others, 2017) and academia (for example, SZ4D) to advance subduction zone science and improve hazard assessment, we are working with our partners to integrate multi-resolution geophysical imaging and geological sampling to characterize offshore margin morphology, including submarine landslides, sediment delivery systems, seafloor seeps, active faults, and upper plate velocity structure in Cascadia. Because uplift and subsidence associated with megathrust earthquakes often crosses the coastline, coordinated onshore-offshore synthesis is vital to this effort.
Globally observed correlations between marine forearc morphology and structure and megathrust earthquake slip, magnitude, and rupture length along subduction margins suggest possible correlations between seismic slip behavior and morphotectonic variability. Systematic morpho-tectonic analyses in Cascadia highlight distinct along-strike variations in morphology and structure that may reflect spatial variations in megathrust earthquake behavior (Watt and Brothers, 2020). Identification and regional mapping of active fault structures will enable further investigation of the links between megathrust behavior and upper plate morpho-tectonics. We plan to investigate the relationships between offshore geologic structure, seafloor morphology, seafloor seeps, and sediment dispersal pathways and depocenters. These efforts will help to identify potential tsunamigenic faults, offshore areas prone to strong shaking, portions of the slope susceptible to landslides, and/or optimal environment(s) for marine paleoseismology studies. Together, this information will provide information fundamental to improving regional hazard assessments and our ability to prepare for future events.
Key scientific questions
- To what extent and how frequently do potentially tsunamigenic upper plate structures rupture with the megathrust?
- How do along strike variations in the morphology and structure of the overriding plate relate to possible segmentation of the megathrust?
- How do the material properties of the wedge vary along the margin, and does this influence the behavior of the underlying megathrust fault?
- How is sediment delivered and redistributed across the continental shelf and slope, and how does that influence the geologic record of past events?
- How does earthquake shaking translate to slope failure, and which areas may be prone to failure in the future?
- What is the role of fluids in subduction zone processes and related hazards?
- How is strain partitioned offshore within the overriding plate?
Main Goals
- Acquire state-of-the-art high-resolution bathymetric, seismic-reflection, ocean bottom seismometer (OBS), and sediment core data across the offshore Cascadia margin
- Apply advanced geophysical and core processing techniques and integrative analyses to identify and characterize submarine active faults, landslides, and sedimentation patterns that may present potential hazards to coastal areas
- Work with scientists on land to link processes and hazards across the shoreline
Targeted Products
- Earthquake recurrence history
- 3D fault/geologic model
- Quaternary sediment distribution and properties
- Bathymetry/backscatter and seep distribution
- Hazard maps: earthquake, landslide, and tsunami
- Event response, such as rapid OBS deployments
Fieldwork Timeline
Fieldwork Completed
Since 2018, the USGS and its partners have completed several research cruises spanning the entire U.S. Cascadia margin (Fig. 3).
- 2018 USGS-NOAA multibeam bathymetry surveys
- 2018 Regional geophysical surveys of southern Cascadia (offshore northern California and southern Oregon)
- 2019 Regional geophysical surveys of northern and central Cascadia (offshore Washington and Oregon)
- 2019 Geophysical surveys and instrumented tripod deployment in and around Astoria Canyon
- 2019 USGS-NOAA Multibeam Bathymetry
- 2019 Seafloor Geodesy cruise
- 2019 Lake Ozette
- 2019 Geophysical surveys and sediment coring in southern Cascadia (northern California)
- Margin-wide Cascadia seismic reflection imaging and ocean bottom sensor deployments [See also, the informational sheet]
- “Unlocking plate motions of the Cascadia subduction zone with seafloor geodesy” — Set two new geodesy sites March 12-17, 2021
Partners/Collaborators
Federal: NOAA, BOEM, NSF, EXPRESS, U.S. National Park Service, and scientists from multiple USGS Mission Areas (Natural Hazards, Ecosystems, Core Science Systems, Energy and Minerals)
State: California Geological Survey, Washington Department of Natural Resources (DNR)
Academic: University of Washington, Humboldt State University, Oregon State University, Scripps Institution of Oceanography, University of Hawaii, Woods Hole Oceanographic Institution
Private: MBARI, Ocean Exploration Trust
