Water Resources

Multimedia

This multimedia gallery represents a collection of high-quality images, videos, webcams, posters, presentations, and documents produced by the Water Resources Mission Area.

Filter Total Items: 1,425
USGS gage 05293000 YELLOW BANK RIVER NEAR ODESSA, MN with High River Water Level From Flood
December 31, 2019

USGS gage 05293000 YELLOW BANK RIVER NEAR ODESSA, MN

USGS gage 05293000 YELLOW BANK RIVER NEAR ODESSA, MN with High River Water Level From Flood.

Attribution: Water Resources
June 2, 2019

U.S. River Conditions From January to June 2019 Data Visualization

This is an animation showing the changing conditions of USGS streamgages from January 1, 2019 to June 1, 2019. The conditions shown range from the driest condition seen at a gage (red open circles) to the wettest (blue closed circles). There is also a purple ring added to indicate gages that are flooding. During the animation, three locations in TN broke record water

...
Attribution: Water Resources
Spring 2019 Midwest flooding data visualization
June 1, 2019

Spring 2019 Midwest flooding data visualization

This DataVisualization shows the severity of flooding in the Midwest . As of June 1, 2019, 17 USGS streamgage sites in red had the highest streamflow for the entire period of record available. Both the Mississippi and the Arkansas rivers are seeing record breaking flows. USGS employees  continue to work extensively deploying equipment and making measurements of streamflow

...
Attribution: Water Resources
USGS employee on a cable way above a river using an Acoustic Doppler Current Profiler
May 9, 2019

USGS employee on a cable way above a river using an ADCP

USGS employee on a cable way above a river using an Acoustic Doppler Current Profiler.

Attribution: Water Resources
USGS Employee conducts a measurement using mechanical current meter
May 9, 2019

USGS Employee conducts a measurement using mechanical current meter

Photograph of USGS employee conducting a measurement in a stream using a mechanical current meter.

Attribution: Water Resources
Photo of USGS scientist operating drone with ground-penetrating radar system over a river
May 6, 2019

USGS tests drone-based ground-penetrating radar

USGS hydrographers collect tens of thousands of streamflow measurements every year. In-water work by personnel is one of the most dangerous aspects of USGS hydrologic studies, especially during high-flow conditions. In May 2019, USGS continued testing of a light-weight, self-contained ground-penetrating radar (GPR) system that can be mounted on a small drone. We are

...
Attribution: Water Resources
USGS Tests Prototype Ground Penetrating Radar Drone
May 1, 2019

USGS Tests Prototype Ground Penetrating Radar Drone

The USGS, in cooperative research and development with GuidelineGEO, tested an 80 GHz self contained ground penetrating radar unit on a DJI Matrice 600 hexcopter (left). This platform was tested for flight performance and for measurement of river channel cross-sectional area as well as river water depth and river width. (Right)

...
Attribution: Water Resources
2019 USGS UAS Aquatic Airshow participants
May 1, 2019

2019 USGS UAS Aquatic Airshow participants

2019 Aquatic Airshow participants at the Androscoggin River in Auburn Maine, May 1, 2019, photograph by Mario Martin-Alciati USGS.  Bottom row L-R: Andy Massey, John Fulton, Sandy Brosnahan, John Young, Russ Lotspeich; Top row L-R: Frank Engel, Tom Orcutt, Per Westholm, Curtis Yaeger, Qassim Abdullah, Mark Harvey, Eric White, Sean Andrews, John Lane, Jeff Kinsey, Jack

...
Attribution: Water Resources
Doppler Radar Mounted On A Drone for Stream Velocity
May 1, 2019

Doppler Radar Mounted On A Drone for Stream Velocity

The sensor mounted on the drone is called the Qcam and is a Doppler radar sensor providing velocity from a hovering position above the river. USGS hydrologic technician (left) aboard a USGS John Boat mounted with Acoustic Doppler Current Profiler observes the Qcam conducting a measurement. (Right) The 3DR solo quadcopter mounted with Qcam is prepared to take off.

Attribution: Water Resources
Photo of drone with ground-penetrating radar system flying close over river surface
May 1, 2019

USGS Tests drone-based ground-penetrating radar for bathymetry

USGS hydrographers collect tens of thousands of streamflow measurements every year. In-water work by personnel is one of the most dangerous aspects of USGS hydrologic studies, especially during high-flow conditions. In May 2019, USGS continued testing of a light-weight, self-contained ground-penetrating radar (GPR) system that can be mounted on a small drone. We are

...
Attribution: Water Resources
USGS LSPIV and Photogrametry Drones
May 1, 2019

USGS LSPIV and Photogrametry Drones

(Left) Frank Engel of the hydrologic remote sensing branch prepares the DJI Mavic Pro quadcopter , while Sean Andrews and Jeff Kinsey of the New England WSC observe. The Mavic was used for Large Scale Particle Image Velocimetry (LSPIV). High quality video was collected to determine the velocity and quantity of the water with

...
Attribution: Water Resources
